Allen Bradley 2711P-T12W22D9P-BSHK 12 inch widescreen color graphics terminal

Description

The Allen Bradley 2711P-T12W22D9P-BSHK is a 12 inch widescreen color graphics terminal designed for seamless integration with Allen Bradley’s FactoryTalk View ME software and various Rockwell automation control platforms including MicroLogix, SLC 500, and ControlLogix. As the central command center for operators to interact with the system, it allows users to send precise commands, monitor real-time process data in detail, and comprehensively view the system status. Its high-resolution widescreen display uses advanced TFT technology to present information in clear graphics, detailed charts, and clear text, enabling operators to quickly and accurately interpret complex data and make informed decisions.

2711P-T12W22D9P-BSHK

Technical specifications:
Model 2711P-T12W22D9P-BSHK
Brand Allen Bradley
Type 12 inch widescreen color graphics terminal
Display size 12 inches (widescreen)
Display type: Color TFT
Installation method: Panel installation
Interface/Bus Ethernet/IP, DF1, DH485
Certification CE, UL, cUL
Touch screen type: resistive
Special function sunlight readable display screen, stainless steel front panel suitable for harsh environments

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

2711P-T12W22D9P-BSHK

Main features and advantages:
Its 12 inch wide screen display provides a broad view of process data, allowing operators to monitor multiple variables simultaneously without the need to frequently switch screens. High resolution display screens ensure that even the most detailed information is clearly visible, reducing the possibility of misunderstandings and improving the accuracy of decision-making. This helps improve product quality, increase production efficiency, and reduce waste.

The intuitive interface design of 2711P-T12W22D9P-BSHKreduces the learning curve for operators, enabling new users to quickly and proficiently use the HMI. This not only reduces training time, but also reduces errors caused by unfamiliarity with the system, further improving operational efficiency. Its sturdy structure, including a stainless steel front panel and a sun readable display screen, makes it ideal for use in harsh industrial environments, including outdoor installations and areas with high levels of dust, moisture, or vibration. The built-in security features can protect automation systems from network threats, ensuring the integrity and security of industrial operations.

Seamless integration with Rockwell Automation’s control platform and communication protocol simplifies system design, installation, and maintenance. It reduces the complexity and time of system debugging, saving valuable resources. With the ability to customize according to specific operational needs, 2711P-T12W22D9P-BSHKcan adapt to constantly changing production requirements, providing long-term value and flexibility for industrial enterprises.

2711P-T12W22D9P-BSHK

Application areas:
In the automotive manufacturing industry, it is used for large assembly lines, managing and monitoring the operation of multiple robot units, conveyor systems, and quality control stations. The large display screen enables operators to view real-time production data such as cycle time, part counting, and quality indicators from different positions on the production line, enabling proactive management and rapid response to any issues.

In the oil and gas industry, operations are typically carried out in harsh outdoor environments, and this HMI is installed in control rooms and offshore platforms. Its sun readable display screen and sturdy structure ensure that operators can clearly view and control critical processes such as pipeline monitoring, wellhead control, and refinery operations even under direct sunlight or adverse weather conditions.

In the field of water and wastewater treatment, 2711P-T12W22D9P-BSHK is used to manage complex water treatment processes. Operators can monitor parameters such as water flow rate, chemical dosage, and wastewater quality on a large screen, and make adjustments to ensure compliance with environmental regulations and efficient water treatment operations. Whether requiring high-precision control, real-time monitoring under harsh conditions, or managing complex multi process systems, Allen Bradley 2711P-T12W22D9P-BSHK has been proven to be a reliable and versatile HMI solution.

2711P-T12W22D9P-BSHK

Related products:
2711P-T10C20D8: A 10 inch color graphics terminal with a smaller display screen, suitable for applications with less data visualization requirements and limited space.
2711P-T15W22D9P-B5A: Equipped with a 15 inch widescreen display, providing a larger viewing area for more comprehensive data presentation, suitable for highly complex control interfaces.
2711P-K7C20D8: A 7-inch color terminal with different performance characteristics, providing an economical and efficient solution for HMI applications ranging from basic to medium complexity.
2711P-RP6T: A sturdy panel mounted terminal designed for extremely harsh industrial environments, with a smaller display screen size compared to 2711P-T12W22D9P-BSHK.
2711P-T6C20D8: A 6-inch color graphic terminal suitable for applications that require compact and basic HMI solutions.
2711P-T22W20D9P: Equipped with a 22 inch widescreen display, designed specifically for applications that require the maximum possible viewing area for detailed data visualization and complex control interfaces.

Installation and maintenance:
Before installing Allen Bradley 2711P-T12W22D9P-BSHK, it is essential to carefully verify that the input voltage of the electrical supply is completely consistent with the specified input voltage range of the terminal. Choose a suitable panel installation location that is convenient for operators to operate and provides sufficient protection against environmental factors such as dust, moisture, and overheating. When making wiring connections, it is essential to strictly follow the detailed wiring diagram provided in the user manual to ensure proper connection with other automation system equipment. Pay special attention to the grounding connection to prevent electrical interference and ensure the safe operation of the terminal.

For communication settings, ensure that the protocol, IP address, and port number are configured correctly to match the connected controller and device. Install the latest version of FactoryTalk View ME software on a compatible computer and ensure that the software license is correctly activated. Before powering on the terminal, double check all connections and configurations to avoid potential issues during startup.

For daily maintenance, regularly clean the surface of the touch screen and display screen with a soft, anti-static, and wear-resistant cloth to remove dust, fingerprints, and other contaminants. This helps maintain the clarity of the display screen and the sensitivity of the touch screen. Regularly check the status indicator lights on the terminal to monitor its operation and pay attention to any error messages or warning signals. Check for signs of wear, tear, or loose connections in the power and communication cables, and promptly replace any damaged cables. Regularly backup the configuration of the terminal to external storage devices to prevent data loss caused by hardware or software failures. If any issues arise, please refer to the comprehensive user manual or contact Rockwell Automation’s technical support team for timely assistance.
