Allen Bradley 2711-T5A8L1 5-inch monochrome graphics terminal

Description

The Allen Bradley 2711-T5A8L1 is a 5-inch monochrome graphics terminal designed for seamless integration with Allen Bradley’s FactoryTalk View ME software and various Rockwell automation control platforms including MicroLogix and SLC 500. It serves as an interface between operators and automation systems, allowing users to send commands, view real-time process data, and monitor system status. Despite using a monochrome display, the2711-T5A8L1 presents information clearly and concisely through text and simple graphics, conveying key details.

2711-T5A8L1

Technical specifications:
Model 2711-T5A8L1
Brand Allen Bradley
Type 5-inch monochrome graphic terminal
Display screen size 5 inches
Display screen type monochrome
Installation method: Panel installation
Interface/Bus DF1, DH485
Certification CE, UL, cUL

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

2711-T5A8L1

Main features and advantages:
Its compact size makes it an ideal choice for applications with limited space, such as small control panels or portable devices. A clear and intuitive display screen ensures that operators can quickly obtain and understand the required information, reducing the time spent interpreting complex data and minimizing the possibility of errors. This in turn improves operational efficiency and helps maintain stable production quality.

This terminal is compatible with Rockwell Automation’s control platform and communication protocol, simplifying system integration. Engineers can utilize existing software and hardware infrastructure to reduce the time and cost required for installation and debugging. Its reliable performance and sturdy structure enable it to withstand the harsh tests of typical industrial environments, reducing the need for frequent maintenance and replacement. With its basic security features, it helps to protect automation systems from unauthorized interference and ensure operational stability. Overall, 2711-T5A8L1 provides an economically efficient and practical solution to improve the efficiency and reliability of industrial processes without the need for large-scale investment.

2711-T5A8L1

Application areas:
In the food and beverage industry, it is usually installed on individual processing machines such as mixers, filling machines, and sealing machines. Operators can use this terminal to adjust machine settings, monitor production speed, and check any quality related issues in real-time. For example, on a small batch coffee roaster, 2711-T5A8L1 can display temperature curves, roasting times, and batch counts, allowing operators to ensure that each batch of products meets the expected quality standards.

In the woodworking industry, it is used for small CNC milling machines and sawing machines. This terminal enables operators to start and stop operations, select cutting programs, and monitor the progress of each task. Its simplicity and ease of use make it suitable for operators of different technical levels. In addition, in small assembly plants, 2711-T5A8L1 can be used to control conveyor systems, manage part feeding mechanisms, and monitor the status of the entire production line, helping to maintain a smooth and efficient workflow.

2711-T5A8L1

Related products:
2711-T6C18: A 6-inch color graphic terminal with enhanced display capabilities, suitable for application scenarios that require more detailed and color data visualization.
2711P-K4M20D: Another 4-inch monochrome terminal with different specifications, providing an alternative option for basic HMI requirements in space constrained environments.
2711-K5A15: An economical monochrome terminal with similar functionality, providing a budget friendly option for simple monitoring and control tasks.
2711P-T6C20D8: A 6-inch color terminal with advanced features designed specifically for more complex HMI applications that require critical connectivity and customization.
2711-T7C15: A 7-inch color graphic terminal that provides a larger display area, suitable for applications that require displaying more information simultaneously.

2711-T5A8L1

Installation and maintenance:
Before installing Allen Bradley2711-T5A8L1, it is necessary to confirm that the input voltage of the electrical supply is within the specified range of the terminal. Choose a suitable panel installation location that is both convenient for operators to access and protects the terminal from excessive dust, moisture, and physical damage. When making wiring connections, please carefully follow the wiring diagram provided in the user manual to ensure proper connection with other equipment in the automation system. Pay attention to correctly terminating communication cables to avoid signal interference and ensure reliable data transmission.

For daily maintenance, regularly clean the surface of the display screen with a soft dry cloth to remove dust and stains that may affect visibility. Regularly check the status indicator lights of the terminal to ensure normal operation and monitor for any error messages. Check for signs of wear, damage, or loose connections in the power and communication cables, and replace them if necessary. It is recommended to regularly backup the configuration of the terminal to a secure storage device to prevent data loss in the event of hardware or software failures. If any problems occur during operation, please refer to the troubleshooting steps in the user manual or contact Rockwell Automation’s technical support team for assistance.
