Allen Bradley 1769-L36ERM High end Programmable Logic Controller

Description

The Allen Bradley 1769-L36ERM is a high-end programmable logic controller designed specifically for the CompactLogix 5370 platform. As a powerful member of the platform, it can seamlessly integrate with various input/output (I/O) modules, human-machine interfaces (HMI), and other automation devices.

1769-L36ERM

Its core function is to receive diverse input signals from a wide range of sensor networks, switches, and smart devices, execute complex control algorithms at extremely high speed and accuracy, and then send precise output signals to actuators, motors, and other devices to drive industrial processes. The Allen Bradley 1769-L36ERM supports multiple programming languages, including ladder diagrams, structured text, functional block diagrams, and sequential functional diagrams, providing engineers with flexibility to develop customized control solutions for different applications. The uniqueness of this PLC lies in its enhanced processing capabilities, expanded memory capacity, and advanced communication capabilities. It is capable of handling extremely complex automation tasks, processing large-scale data in real-time, and effectively communicating with various devices in different industrial networks, making it an ideal choice for large-scale and complex automation projects.

1769-L36ERM

Main features and advantages:
In terms of functional performance, it is equipped with a high-speed multi-core processor that can execute a large number of instructions per second, respond to changing input conditions in real time, and ensure real-time control of the most complex industrial processes. Its large capacity memory can store a wide range of complex control programs, detailed historical data, and advanced algorithms, facilitating in-depth process analysis, optimization, and predictive maintenance. This PLC supports a comprehensive communication protocol suite, including EtherNet/IP, DeviceNet, ControlNet, and OPC UA, and can seamlessly integrate with various industrial equipment, cloud platforms, and enterprise management systems. This connectivity enables real-time data sharing, remote monitoring, and intelligent decision-making throughout the entire industrial ecosystem. In addition, it also has advanced built-in motion control functions, supporting multi axis motion control, suitable for applications that require precise and coordinated motion of multiple servo motors, such as robot assembly and high-precision machining.

In terms of hardware design, the Allen Bradley 1769-L36ERM has a compact and durable structure. Its industrial grade casing can effectively prevent dust, moisture, vibration, and electromagnetic interference, ensuring reliable operation in harsh industrial environments. Modular design facilitates installation, expansion, and maintenance. With the development of automation systems, users can easily add or replace I/O modules without interrupting the entire system. To ensure long-term reliability, the PLC is equipped with advanced self diagnosis and self recovery functions. It will continuously monitor internal components, power supply, and communication links. When a malfunction occurs, it can automatically isolate the problem area, re route data, and even attempt self repair, thereby minimizing downtime and ensuring uninterrupted production.

1769-L36ERM

Technical specifications:
Model 1769-L36ERM
Brand Allen Bradley
Type Programmable Logic Controller
Power supply 24 VDC
Processor type: High performance multi-core
Communication ports EtherNet/IP, DeviceNet, ControlNet, OPC UA
Built in motion control with multiple axes
Working temperature -40 ° C -70 ° C
Installation method: DIN rail
Certification CE, UL, cUL
Protection level IP20

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

Application areas:
In the field of large-scale electronic product manufacturing, the Allen Bradley 1769-L36ERM plays a crucial role in managing complex assembly lines. It can accurately coordinate the operation of the picking and placing machine, welding robot, and quality inspection system. By processing massive real-time data from sensors that monitor component placement, temperature, and electrical parameters, it ensures the production of high-quality electronic products at a faster speed. In large-scale pharmaceutical production that strictly follows regulations and requires high precision process control, this PLC monitors and controls every aspect of the production process. From precise mixing of raw materials to sterilization and packaging of finished products, it always maintains optimal process conditions to ensure the safety and effectiveness of drugs. In the field of advanced material processing, such as aerospace alloy manufacturing, the Allen Bradley 1769-L36ERM controls the complex operations of melting, forging, and heat treatment equipment. It adjusts process parameters in real-time based on material characteristics and production requirements to produce high-performance materials.

1769-L36ERM

Related products:
Allen Bradley 1769-IF16H – an advanced analog input module, perfectly paired with 1769-L36ERM. It enables PLC to receive and process high-precision analog signals from various sensors, significantly enhancing the system’s monitoring and control capabilities for applications that require precise measurement of physical parameters.
Allen Bradley 1769-OB32E – a high-density discrete output module that works in conjunction with 1769-L36ERM. It can send control signals to a large number of actuators, relays, and other output devices, facilitating precise control of complex industrial processes with high output requirements.
Allen Bradley 2711P-K15C4A8L1- a large screen, high-resolution human-machine interface (HMI). It provides an intuitive and detailed interface for operators to monitor and control 1769-L36ERM. Equipped with touch screen operation, real-time 3D data visualization, and advanced graphical interface, it enhances user experience, achieves efficient operation and quick decision-making, especially suitable for complex automation systems.
Allen Bradley 1769-PA4- a high-capacity power module suitable for the CompactLogix 5370 platform. It ensures stable and reliable power supply for 1769-L36ERM and other connected modules even under heavy load conditions, ensuring the overall performance and stability of the automation system.
Allen Bradley 1769-EN2TR – an Ethernet router module that can be integrated with 1769-L36ERM. It manages and optimizes network traffic, achieving seamless communication between different devices and subnets in large and complex industrial networks, ensuring smooth data transmission and efficient operation of automation systems.

1769-L36ERM

Installation and maintenance:
Careful planning and precise execution are crucial when installing the Allen Bradley1769-L36ERM. Before installation, it is essential to thoroughly confirm that the power supply voltage is a stable 24 VDC. Any deviation from the specified voltage may damage the PLC or even the entire automation system. Ensure that the control cabinet has sufficient space not only for placing the PLC itself, but also for future expansion of I/O modules, power supply, and proper ventilation to prevent overheating. Use high-quality installation hardware to securely mount the PLC onto the DIN rail, ensuring that it can withstand any vibrations or impacts during operation. Strictly follow the detailed wiring diagram and installation guide provided when wiring the PLC. Pay special attention to correctly connecting input and output signals, power lines, communication cables, and grounding wires to minimize electromagnetic interference and ensure reliable communication.

Develop regular and comprehensive maintenance plans during the maintenance process. Regularly check all connecting cables for signs of wear, damage, or loose connections, and replace them promptly if necessary. Regularly clean the casing and internal components of the PLC to remove dust, debris, and any contaminants that may affect heat dissipation and component performance. Regularly backup the programs, data, and configuration settings of the PLC to external storage devices and store these backups in a secure location. This is crucial for preventing data loss caused by hardware failures, power outages, or other unexpected events. Keep the firmware of the PLC at the latest version released by Allen Bradley. These firmware updates typically include performance enhancements, security patches, new features, and compatibility improvements with the latest automation technologies, ensuring that PLCs remain at the forefront of technology and continue to operate at maximum efficiency.
