Allen Bradley 1747-L552 Programmable Logic Controller

Description

The Allen Bradley 1747-L552 is a powerful programmable logic controller that can be called the “brain” of industrial automation systems. As an important component of the Allen Bradley SLC 500 series, it can seamlessly integrate with various input/output (I/O) modules, human-machine interfaces (HMI), and other automation equipment. Its main function is to execute pre programmed logic based on input signals received from sensors and other devices, and then send control signals to actuators and output devices. The Allen Bradley 1747-L552 uses ladder diagram programming, which is a widely recognized and easy-to-use programming language in the field of industrial automation, enabling engineers and technicians to easily develop, modify, and maintain control programs. Programmable logic controller

1747-L552

Main features and advantages:
It can handle various applications ranging from simple single machine control to complex multi system automation projects. Whether small factories want to upgrade their existing automation equipment or large industrial enterprises want to implement new production lines, the Allen Bradley 1747-L552 can be customized according to specific needs, providing cost-effective and reliable control solutions.
In terms of functional performance, it has a fast processing speed and can execute thousands of instructions per millisecond. This enables it to respond quickly to changing input conditions, ensuring real-time control and monitoring of industrial processes. It has a large memory capacity that can store a large amount of control programs and data, which is crucial for handling complex automation tasks. The PLC also supports multiple communication protocols, including DH-485 and remote I/O, facilitating seamless integration with other devices and systems in the network. This helps to achieve centralized monitoring and control, as well as data sharing between different parts of industrial facilities.
In terms of hardware design, the Allen Bradley 1747-L552 is capable of withstanding harsh industrial environments. Its sturdy casing is dustproof, moisture-proof, and vibration resistant, ensuring reliable operation even under the most demanding conditions. Modular design facilitates installation and expansion, and with the development of automation systems, additional I/O modules can be added. In order to achieve long-term reliability, the PLC has a built-in self diagnostic function. It will continuously monitor internal components and operational status, detect potential faults or anomalies in advance, and issue alerts to operators, which helps minimize downtime and ensure production continuity.

1747-L552

Technical specifications:
Model 1747-L552
Brand Allen Bradley
Type Programmable Logic Controller
Power supply 120/240 VAC
Processor type 16 bit
Communication port DH-485, remote I/O
Working temperature: 0 ° C -60 ° C
Installation method: DIN rail
Certification CE, UL, cUL
Protection level IP20

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

1747-L552

Application areas:
In the automobile manufacturing factory, Allen Bradley 1747-L552 is responsible for overseeing complex assembly lines. It coordinates the movements of numerous robotic arms, conveyor systems, and testing equipment to ensure precise positioning, assembly, and testing of every automotive component. From controlling the welding sequence of car frames to managing the installation of electrical systems, this PLC ensures smooth production processes and high-quality products.
In chemical processing facilities, it plays a critical role in monitoring and controlling chemical reactions, managing the flow of raw materials, and ensuring strict compliance with safety regulations. The Allen Bradley 1747-L552will continuously analyze data from various sensors, adjust process parameters in real time to optimize production yield while ensuring operational safety. In large-scale material handling operations such as ports and warehouses, it controls the operation of cranes, forklifts, and automated guided vehicles (AGVs), achieving efficient loading, unloading, and storage of goods.

1747-L552

Related products:
The Allen Bradley 1747-L532 is a low-end version of the 1747-L552, suitable for small automation projects or applications with relatively less complex control requirements. It provides basic PLC functions at a more affordable price.
Compared to the 1747-L532, the Allen Bradley 1747-L542 has enhanced memory and processing capabilities, making it ideal for small and medium-sized projects that require more extensive control programs and data processing.
The Allen Bradley 1746-IB16 is an input module that can be used in conjunction with the 1747-L552, allowing the PLC to receive signals from various sensors and input devices, expanding the system’s data acquisition capabilities.
The Allen Bradley 1746-OB16E is an output module that works in conjunction with the 1747-L552 to send control signals to actuators and output devices, achieving precise control of industrial processes. The Allen Bradley 2711P-K10C4A8 is a human-machine interface (HMI) that provides operators with an intuitive interface for monitoring and controlling the 1747-L552. With the help of this HMI, operators can view real-time process data, adjust control parameters, and easily troubleshoot.
The Allen Bradley 1747-P4R is a power module specifically designed for the SLC 500 series, which provides stable power to the 1747-L552 and other connected modules, improving the reliability of the entire automation system.

Installation and maintenance:
When installing the Allen Bradley 1747-L552, the following important steps should be followed. Before installation, carefully verify whether the electrical power supply voltage matches the requirements of the PLC. Connecting the PLC to the wrong voltage source may cause serious damage to the equipment. Ensure that the control cabinet has sufficient space to accommodate the PLC and any additional I/O modules or accessories. Install the PLC firmly on the DIN rail, ensuring its secure installation to prevent vibration from affecting its performance. When wiring PLC, strictly follow the provided wiring diagram, paying special attention to correctly connecting input and output signals, power supply, and communication cables.

During maintenance, regularly check the connecting cables for wear, damage, or looseness. Regularly clean the casing of the PLC to remove dust and debris, as dust and debris may affect its heat dissipation and performance. Regularly backing up the PLC program is also very important to prevent hardware failures from causing data loss. Maintaining firmware updates for PLCs is crucial, as new firmware versions typically include performance improvements, security patches, and compatibility enhancements with other automation components, ensuring that PLCs can continue to operate efficiently and reliably.
