Real-World Use & Application Scenarios
The ABB UBC717AE01 HIEE300927R0101 is a high-voltage inverter power module designed for demanding industrial automation and control systems. It is widely utilized in power plants, heavy manufacturing, and energy-intensive industries where reliable DC to AC power conversion and inverter control are critical. This module is commonly applied in turbine control systems, variable frequency drives, and other high-power electric motor control applications, ensuring smooth, efficient, and precision power delivery.
In industrial automation, the ABB UBC717AE01 provides critical power conditioning and conversion functions essential for optimizing system performance and energy efficiency. Its application extends to environments requiring rapid response to fluctuating load demands, stable output waveform generation, and robust operation under harsh electrical and mechanical conditions.
Engineers design this module into control racks facilitating real-time inverter control, improving plant safety, equipment lifespan, and process efficiency.
- UBC717AE01 HIEE300927R0101
Product Introduction & Positioning
The ABB UBC717AE01 HIEE300927R0101 is a high-voltage inverter accessory module engineered as part of ABB’s high-performance automation portfolios. Designed to manage and control power electronic switching devices, this module offers robust functionality in inverter systems capable of handling outputs up to 250 kW.
With an inverter efficiency exceeding 98%, the module minimizes energy loss, contributing to sustainable and cost-effective operations. Its compact form factor fits industrial cabinet designs (dimensions roughly 400 mm x 150 mm x 200 mm), enabling versatile integration into existing power control architectures.
The module supports input voltages of 24 VDC and outputs AC voltages up to 400 VAC with currents reaching 10 A, providing ample power for driving industrial motors and other equipment. This flexibility in power output and control functionality makes the UBC717AE01 a vital unit for modern industrial power electronics.
Key Technical Features & Functional Benefits
The ABB UBC717AE01 boasts high inverter efficiency at or above 98%, helping reduce heat dissipation and enhancing energy savings. Its precise power module controls DC-AC conversion efficiently to maintain stable voltage and frequency outputs, supporting varied motor operations and process control needs.
Designed to operate reliably across industrial temperature ranges from -20°C to +70°C, the module ensures continuous performance in challenging environments. It features robust internal circuit protection and complies with IP20 protection standards, balancing durability with servicing accessibility.
The module’s structural design facilitates straightforward installation and maintenance, with optimized mounting configurations suitable for industrial control cabinets. Integration with ABB’s control systems permits seamless communication and fast response to control commands.
Detailed Technical Specifications
| Parameter | Value |
|---|---|
| Model | UBC717AE01 HIEE300927R0101 |
| Brand | ABB |
| Product Type | High-Voltage Inverter Power Module |
| Output Power | Up to 250 kW |
| Inverter Efficiency | ≥ 98% |
| Input Voltage | 24 V DC |
| Output Voltage | Up to 400 V AC |
| Output Current | Up to 10 A |
| Operating Temperature Range | -20 to +70 °C |
| Protection Class | IP20 |
| Dimensions (L x W x H) | 400 mm x 150 mm x 200 mm |
| Weight | Approx. 1.5 kg |
Related Modules or Compatible Units
PM866-2 – Industrial controller for high-speed automation and control.
PU519 – Real-time accelerator module supporting enhanced processing speed.
DO810 – Digital output module complementing power modules for control integration.
REG216 – Numerical protection relay serving critical power protection needs.
IDPG 940128102 – Advanced signal processing module for complex automation tasks.
Installation Notes & Maintenance Best Practices
Install the ABB UBC717AE01 in well-ventilated control cabinets with proper grounding and shielding to prevent electromagnetic interference. Ensure adequate clearance around the module for heat dissipation and ease of maintenance access.
Regular maintenance includes checking connection integrity, cleaning dust and debris around cooling paths, and applying ABB-recommended firmware updates. Utilize diagnostic data and status LEDs for proactive condition monitoring and reliable module operation.
