ABB REF620E-F NBFNAAAAND1BNN1X is a multifunctional protection and control relay with diverse functions, playing a key role in substation automation systems. As a member of ABB’s innovative product line, it can seamlessly interface with various field devices such as current transformers, voltage transformers, and circuit breakers. This relay supports key industrial communication protocols, including IEC 61850, which enables seamless integration with other components in the automation system.
REF620E_F NBFNAAAANDA1BNN1X
Its modular design is easy to install and can adapt to different system requirements. This relay has a built-in self diagnostic function that can continuously monitor its own performance, detect and report any potential abnormal situations to the operator. This proactive approach ensures high reliability operation and reduces the possibility of unexpected power outages. It can be integrated into different control platforms and chassis systems, serving as the core hub for managing system operation, with everything from fault protection to precise measurement of electrical parameters.
REF620E_F NBFNAAAANDA1BNN1X
Technical specifications:
Model REF620E-F NBFNAAAAND1BNN1X
Brand ABB
Type multifunctional protection and control relay
Normal operating temperature range: -25 ° C to+55 ° C; Extended range: -40 ° C to+70 ° C
Installation method designed for standard cabinet installation
Dimensions: Width: 164mm, Height: 260mm, Depth: 155mm
Weight approximately 4.5 kilograms
Interface/Bus Ethernet (RJ-45), supporting multiple fieldbus options
Certification of CE, RoHS, and other related industry standards
Supports protocols IEC 61850, IEC 60870-5-103, Modbus
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
REF620E_F NBFNAAAANDA1BNN1X
Main features and advantages:
Its design is sturdy and durable, capable of operating in harsh industrial environments, ensuring long-term stable performance. Advanced protection functions are a major advantage, which can quickly detect and isolate electrical faults, minimize damage to connected equipment, and reduce unplanned downtime. Its precise measurement function enables operators to manage energy consumption more effectively, resulting in significant cost savings. Easy integration and modular design reduce engineering time and effort during system setup and upgrade processes, lowering overall project costs. In addition, by ensuring compliance with industry-leading standards, it provides security for your power system, allowing you to have peace of mind in terms of operational reliability.
REF620E_F NBFNAAAANDA1BNN1X
Application areas:
In the field of power generation, it is used to protect and control the feeders that transmit electricity from power plants to the grid, ensuring stable power transmission even in the event of load fluctuations. Its fast response fault detection and isolation functions are crucial for maintaining grid stability.
In the manufacturing industry, especially in high-precision production process factories that require highly stable power supply, this relay can protect electrical infrastructure from interference that may cause production interruptions. In addition, in the field of transportation, such as railway substations, ABB REF620E-F NBFNAAAAND1BNN1X ensures reliable power distribution for trains, ensuring smooth and safe operation of trains.
REF620E_F NBFNAAAANDA1BNN1X
Related products:
REF620E-G NBFNAAAANDA1BNN2X: Provides enhanced communication capabilities, suitable for complex network settings that require high-speed data transmission.
REF620-A: Early model with basic protection and control functions, suitable for power systems with low requirements.
REF620-B: Equipped with additional control algorithms to provide deeper control over the operation of the power system.
REF620-C is designed to handle more input and output channels, making it ideal for large-scale industrial applications.
REF620-D incorporates advanced redundancy features to ensure continuous operation in critical mission scenarios.
REF620-E is specifically optimized for renewable energy: optimized for the integration and management of renewable energy sources such as solar and wind farms.
REF620E_F NBFNAAAANDA1BNN1X
Installation and maintenance:
Before installing ABB REF620E-F NBFNAAAAND1BNN1X, it is essential to thoroughly check its communication protocol for compatibility with existing automation systems. Ensure that the voltage and current ratings of the connected devices match the specifications of the relay. Sufficient ventilation must be provided for relays to prevent overheating, especially in high-density installation environments. Verifying and updating firmware to the latest version can improve performance and security.
For daily maintenance, it is necessary to regularly monitor the LED status indicator lights of the relay in order to quickly identify any abnormal situations. Regularly inspecting connectors for signs of wear, corrosion, or loose connections is crucial for maintaining reliable operation. Regular (such as annual) comprehensive system testing helps ensure that all protection and control functions are functioning properly.
