ABB REF615C_E HCFDACADABC2BAN11E is a specialized feeder relay belonging to ABB’s Relion product series and 615 protection and control product series. It is designed as the core component of the substation automation system. In terms of its position in the automation system, it directly interfaces with various on-site devices such as current transformers, voltage transformers, circuit breakers, and other protective equipment.
ABB REF615C_E HCFDACADABC2BAN11E
It supports multiple communication protocols, including IEC 61850 with GOOSE messages, IEC 60870-5-103, and Modbus, which enables seamless communication with other devices in the network. This relay can be integrated into different control platforms and baseboard systems. It adopts a modular design, which facilitates the installation and replacement of components. In addition, it also has self-monitoring function, which means it can continuously monitor its own performance and detect any abnormal situations, ensuring high reliability operation.
ABB REF615C_E HCFDACADABC2BAN11E
Technical specifications:
Model REF615C_E HCFDACADABC2BAN11E
Brand ABB
Type feeder protection and control relay
Normal operating temperature range: -25 ° C to+55 ° C; short-term: -40 ° C to+85 ° C
Installation method designed for easy installation in standard cabinets
Dimensions: Width: 164mm, Height: 160mm, Depth: 155mm
The weight of the relay is about 3.5 kilograms, and the replacement unit is about 1.8 kilograms
Interface/Bus Ethernet (RJ-45 for 100Base TX, LC for 100Base FX fiber), supporting multiple fieldbus options
Certification of CE, RoHS, and other related industry standards
Supports protocols IEC 61850, IEC 60870-5-103, Modbus
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
ABB REF615C_E HCFDACADABC2BAN11E
Main features and advantages:
Its sturdy structure enables it to withstand harsh industrial environments and ensure long-term stable operation. Advanced protection functions can reduce the risk of equipment damage caused by electrical faults, thereby reducing unplanned downtime. With its precise measurement capability, it can achieve better energy management, thereby reducing operating costs. The modular design and ease of integration can reduce engineering costs during system installation and upgrade processes. At the same time, it can ensure that your power system meets industry standards, allowing you to rest assured in terms of safety and reliability.
ABB REF615C_E HCFDACADABC2BAN11E
Application areas:
In power plants, it is crucial for protecting and controlling the feeders that distribute electricity from the generating units to the grid. Here, the ability of relays to handle high-power loads and high-speed fault detection is crucial for maintaining the stability of power supply.
In the manufacturing industry, especially for large production lines that require continuous and stable power supply, ABB REF615C_E HCFDACADABC2BAN11E is used to protect the power system from potential production interruption faults.
In the oil and gas industry, critical operations such as pumping and processing require reliable power supply, and this relay ensures the integrity of the power distribution network under challenging environmental conditions.
ABB REF615C_E HCFDACADABC2BAN11E
Related products:
REF615C_E HCFEAEAGAABC2BAA11E: Similar in functionality, but communication options may be different or optimized for specific sub applications in industrial power systems.
REF615-A: It has basic feeder protection functions and is suitable for less complex power systems or as an economical alternative in certain applications.
REF615-B: Provides additional control functions for applications that require deeper control of the power system.
REF615-C has a higher channel density and is suitable for applications with limited space but requiring a large number of input and output channels.
REF615-D focuses on enhancing communication capabilities, supporting more advanced or specialized communication protocols for seamless integration in complex network settings.
REF615-E has enhanced redundancy capabilities, ensuring continuous operation even in the event of component failures in critical applications.
REF615-F is designed for harsh environments: capable of withstanding extreme temperatures, high humidity, and other harsh environmental conditions, suitable for outdoor or challenging industrial environments.
Installation and maintenance:
Before installing ABB REF615C_E HCFDACADABC2BAN11E, it is essential to verify the compatibility of the communication protocol with your existing system. Check whether the voltage level and current rating of the connected equipment meet the requirements of the relay. Ensure sufficient space around the relay to ensure good ventilation and prevent overheating. In addition, it is important to ensure that the firmware of the relay is the latest version, as this can improve performance and fix any known issues.
For daily maintenance, it is necessary to regularly check the LED status indicator lights on the relay to quickly identify any abnormal situations. Regularly check the connectors for signs of wear or corrosion, as this may affect the reliability of the connection. Conduct comprehensive system testing at least once a year to ensure that all protection and control functions are functioning properly.
