ABB PP846 3BSE042238R1 operation panel

Description

ABB PP846 3BSE042238R1 Product Introduction:
ABB PP846 3BSE042238R1 is an operation panel belonging to ABB’s highly acclaimed Panel 800 series. As an operation panel, it is an important part of industrial control systems, facilitating communication between human operators and underlying automation processes. It is designed for seamless integration with ABB’s range of automation systems, such as those used in the Advant AC 800M and Advant-800XA configurations. In the overall architecture of the control system, PP846 3BSE042238R1 is located on the end facing the operator. It receives data about process variables from the control system and presents this information to operators in an easily understandable format. Conversely, it allows operators to input commands and settings, which are then transmitted to the control system for execution. Engineers and integrators highly appreciate its ease of use and ability to quickly configure to meet specific industrial needs.

PP846 3BSE042238R1

Main advantages and features:
One of the key advantages of PP846 3BSE042238R1 is its display capability. It is equipped with a 10.4-inch TFT color LCD display with a resolution of 800 x 600 pixels, providing clear and sharp visual effects. This ensures that operators can easily read process data, view graphical representations of system status, and distinguish between different alarm levels. The resistive touch screen interface, paired with 16 programmable function keys, enables intuitive operation. Whether it’s quickly adjusting process parameters or accessing complex menus, the operation is smooth and efficient.

In terms of hardware design, the panel is designed to withstand harsh industrial environments. It is installed in a sturdy but lightweight die cast, powder coated aluminum casing with a front panel protection rating of IP65/IP66. This means it can withstand dust, water splashes, and other harsh conditions commonly found in industrial environments. -The working temperature range of 30 ° C to 70 ° C and a maximum humidity of 95% further demonstrate its durability, ensuring reliable operation even under extreme conditions.

Compatibility is another major advantage of it. ABB PP846 3BSE042238R1 is equipped with a built-in Ethernet port, which can seamlessly connect with other devices in industrial networks. It supports multiple languages, including English, German, French, Spanish, Italian, Chinese, Japanese, and Korean, suitable for cross-border industrial operations. This broad compatibility enables it to easily integrate with different control systems and devices, expanding its practicality in various industrial environments.

In terms of long-term reliability, ABB ensures that the panel meets high standards. The strict testing during the manufacturing process ensures its long-term trouble free operation. By using high-quality components and advanced manufacturing technology, its durability has been improved, the need for frequent replacement has been reduced, and downtime has been minimized to the greatest extent possible.

PP846 3BSE042238R1

Technical specifications:
Model ABB PP846 3BSE042238R1
Brand ABB
Type operation panel
Power supply 24 VDC
Working temperature -30 ° C to 70 ° C
Diverse installation methods (designed specifically for industrial control panels)
Size 38.1 cm x 25.4 cm x 7.6 cm
Weight 2.4 kilograms
Interface Ethernet
Certification CE, UL, etc
Display screen size 10.4 inches
Display screen type TFT color LCD display screen
Display screen resolution 800 x 600 pixels
Touch screen type: resistive
16 programmable function keys

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

PP846 3BSE042238R1

Related products:
ABB PP840 3BSE042237R1- a related operation panel in the same series, with slightly different appearance, may be more suitable for applications with limited space.
ABB Panel 800- PP880 3BSE042240R1- Provides enhanced graphics functionality for applications that require more detailed visualization of complex industrial processes.
ABB AC 800M CI560 3UBRC980002R0001- A communication module that can be paired with ABB PP846 3BSE042238R1 to expand communication options within the control system.
ABB DI820 3BSE008512R1- an input module that can be used in conjunction with an operation panel to provide additional input channels for control systems.
ABB AI523 1SBP250300R0001- An analog input module that can be integrated with ABB PP846 3BSE042238R1 into the system, suitable for applications that require precise monitoring of analog signals.
ABB PM581B1 1SAP140100R0100- A processor module that can be used as part of the overall control system architecture using ABB PP846 3BSE042238R1 to enhance system processing capabilities.
ABB DSQC-266G – a module commonly used in robot applications that can interface with ABB PP846 3BSE042238R1 in manufacturing environments involving robot operations.

PP846 3BSE042238R1

Application areas:
In manufacturing plants, ABB PP846 3BSE042238R1 serves as the interface between operators and complex production lines. For example, in an automotive assembly plant, operators rely on this device to monitor the status of the robotic arm, adjust production speed, and receive real-time alerts about any malfunctions during the assembly process. In the oil and gas industry, it is deployed at control stations to regulate the flow of oil and gas in pipelines, ensuring safe and efficient transportation. The power generation facility uses ABB PP846 3BSE042238R1 to monitor the performance of the generator, control voltage levels, and manage power distribution. It can provide a user-friendly interface for the control and monitoring of industrial processes, making it indispensable in these industries.

PP846 3BSE042238R1

Installation and maintenance:
Before installing ABB PP846 3BSE042238R1 several factors need to be considered. Firstly, ensure that the control panel to be installed has sufficient space to accommodate the device’s dimensions of 38.1 cm x 25.4 cm x 7.6 cm. Proper ventilation is crucial for preventing panel overheating, especially considering its operating temperature range. In addition, proper grounding is necessary to prevent electrical interference and ensure the safety of operators. Carefully check the power requirements to ensure that the 24 VDC power supply is stable and free from voltage fluctuations.

For maintenance, it is recommended to conduct regular visual inspections. Check for any physical signs of damage to the casing, such as cracks or dents, which may expose internal components. Check if there are any responsive areas on the touch screen and if the function keys are working properly. Signal diagnosis should be conducted regularly to ensure the accuracy of data transmitted to and from the panel. In addition, pay attention to ABB’s firmware updates. These updates typically include error fixes, performance enhancements, and new features, so installing them at appropriate intervals will help maintain smooth operation of ABB PP846 3BSE042238R1
