ABB PFTL101B 10KN 3BSE004197R1 Pressure magnetic load-bearing sensor

Description

ABB PFTL101B 10KN 3BSE004197R1 Product Description:
ABB PFTL101B 10KN 3BSE004197R1 is a highly anticipated pressure magnetic load-bearing sensor in the field of industrial measurement. According to the model, its rated load is 10 kilonewtons (kN), which is approximately equivalent to a force of 1000 kilograms. This rated load value makes it suitable for many industrial scenarios that require a certain level of weight measurement.

ABB PFTL101B 10KN 3BSE004197R1

The operation of piezoelectric sensors is based on the principle that the magnetic permeability of magnetic materials changes under the action of mechanical force.ABB PFTL101B 10KN 3BSE004197R1 is made of solid stainless steel and has a specific coil winding structure. When mechanical force is applied to the sensor, it induces an induced potential, which is then converted into a direct current voltage signal proportional to the measured force, thereby achieving accurate measurement of force or weight.

ABB PFTL101B 10KN 3BSE004197R1

Main features and advantages:
High precision and reliability: With advanced manufacturing processes and high-quality materials, this sensor ensures high measurement accuracy and can provide reliable weight data for various applications, meeting the industry’s strict requirements for high-precision measurement.
Fast response: It has the characteristic of fast response, which can monitor the weight changes of materials in real time and accurately. This advantage is particularly critical in dynamic weighing scenarios that require timely response to weight changes, which helps to improve the efficiency and stability of the production process.
High protection level: With a high protection level, it can work stably in various complex and harsh environmental conditions, such as dusty, humid, etc., greatly expanding its application range and reducing measurement errors and equipment failures caused by environmental factors.
Excellent frequency characteristics: The highest response frequency can reach 500Kpps (pulses per second), which is 2.5 times the pulse frequency received by traditional drivers. This makes it excellent in processing high-speed weight signals and can quickly and accurately capture changes in weight data.
Intelligent coil current characteristics: When the step pulse stops for more than 100ms, the coil current automatically decreases to half of the set current. This intelligent current control method helps reduce energy consumption, extend the service life of the sensor, and also reduce equipment heating and other issues.
Convenient signal input and output: adopting photoelectric isolation signal input/output, compatible with 5V, 12V, 24V signal input, no need for external current limiting resistors, convenient for integration with different types of control systems, reducing the complexity and cost of system construction.
Flexible drive current regulation: The effective value of the drive current can be adjusted from 1.2A/phase to 4.5A/phase in 16 levels, which can be flexibly adjusted according to the needs of actual application scenarios to achieve the best measurement performance.
Wide power input range: Adopting a single power input with a voltage range of AC80V-220V, it adapts to the power supply conditions of different regions and occasions, improving the universality and applicability of the equipment.

ABB PFTL101B 10KN 3BSE004197R1

Application areas:
Industrial automation: Used in industrial automation production lines to accurately measure and control the weight of materials, ensuring consistency in the production process and stability in product quality. For example, in the packaging process of industries such as food and medicine, the weight of packaging materials can be precisely controlled to avoid weight deviations.
Robot technology: provides precise force feedback for robots in tasks such as handling and assembly, enabling them to operate objects more accurately, avoiding damage or operational errors caused by improper force, and improving the accuracy and safety of robot operations.
Material handling: In logistics warehousing, port terminals and other material handling scenarios, it is used to monitor the weight of goods in real time, optimize the handling process, prevent overloading or underloading, and improve the efficiency and safety of logistics transportation.
Manufacturing and processing equipment: In industries such as mechanical manufacturing and metal processing, it can be used to measure the weight of processed parts, ensure that the parts meet design requirements, and monitor the load weight during equipment operation to prevent equipment damage due to overload and ensure production continuity.

ABB PFTL101B 10KN 3BSE004197R1

ABB PFTL101B 10KN 3BSE004197R1
