ABB PFTL101A 2.0KN 3BSE004172R1 high – performance force transducer

Description

ABB PFTL1101 2.0KN 3BSE004172R1 Product Introduction：

The ABB PFTL101A 2.0KN 3BSE004172R1 is a high – performance force transducer that seamlessly integrates into industrial automation systems. It works by converting mechanical force into an electrical signal, which can then be easily processed by control systems. The transducer features a strain – gauge based sensing element, which deforms under the applied force, causing a change in electrical resistance that is proportional to the force magnitude.

This transducer interfaces with a variety of control platforms through its electrical output. It supports standard electrical interfaces, allowing it to communicate effectively with PLCs (Programmable Logic Controllers), data acquisition systems, and other automation devices. In an automation stack, it typically sits at the sensor layer, feeding real – time force data to the control and monitoring systems. For example, in a robotic assembly line, the ABB PFTL101A 2.0KN 3BSE004172R1 can be installed on the robotic arm to measure the force applied during part handling. The electrical signal generated by the transducer is sent to the PLC, which uses this data to adjust the arm’s movements, ensuring that the correct amount of force is applied at all times. Its compact design and easy – to – use mounting options make it a convenient addition to any existing automation setup.

Technical specifications:
Model: PFTL1101 2.0KN  3BSE004172R1
Brand: ABB
Type: Tension Sensor
Maximum rated load: 2.0KN
Compliant with standards: ABB, RoHS

Contact Us
Phone:+86 16626708626
WhatsApp/WeChat:+86 16626708626
Email: 3772179818@qq.com

Application areas:
Choosing ABB PFTL1101 2.0KN 3BSE004172R1 has brought many practical application advantages to industrial operations. The force sensor has been carefully designed to ensure long-term reliable performance and minimize unplanned downtime. In industries such as food processing or electronic manufacturing where continuous production is crucial, any interruption caused by sensor failure can result in significant losses. The robust structure and advanced sensing technology of ABB PFTL1101 2.0KN 3BSE004172R1 reduce the risk of failure, providing peace of mind for factory managers and engineers.

Its high-precision force measurement capability improves product quality. By ensuring that each component is assembled or processed with precise force, manufacturers can reduce the occurrence of defects, thereby improving customer satisfaction and market reputation. This sensor is easy to integrate into existing automation systems and also reduces engineering costs. It can be quickly installed and calibrated, minimizing the time and resources required for system upgrades or new installations. In addition, its compatibility with standard industrial protocols means that it can seamlessly collaborate with various control and monitoring devices, simplifying the overall automation process.

Application areas:
ABB PFTL1101 2.0KN 3BSE004172R1 has been widely used in multiple industries. In the automotive industry, it plays a crucial role in the assembly process of engines and frames. When installing engine components such as cylinder heads and connecting rods, sensors measure the force applied by the tightening tool to ensure that the bolts are tightened to the correct torque specification. This not only ensures the structural integrity of the engine, but also improves its performance and service life.

In the packaging industry, ABB PFTL1101 2.0KN 3BSE004172R1 is used to monitor the forces applied during packaging sealing and compression processes. By accurately measuring force, manufacturers can ensure good packaging sealing and prevent product damage during transportation and storage. In the field of construction machinery manufacturing, it is used to test the strength and durability of components. For example, when testing hydraulic cylinders, sensors measure the force applied to the cylinder to verify its performance under different load conditions.

Related products:
ABB PFTL102A 5.0KN 3BSE004173R1：ABB PFTL101A 2.0KN 3BSE004172R1 The high-capacity version is suitable for applications that require greater force measurement, such as heavy material handling or testing of large construction equipment.
ABB PFTL0101A 1.0KN 3BSE004171R1: Suitable for applications that require precise measurement of small forces, such as precision assembly processes for small electronic components.
ABB PFTL101B 2.0KN 3BSE004172R2: Designed for use in harsher and more challenging industrial environments with higher durability and environmental resistance.

Installation and maintenance:
Preparation before installation: Before installing ABB PFTL1101 2.0KN 3BSE004172R1, it is necessary to ensure that the installation surface is clean, flat, and free of any debris or damage. Check the input voltage requirements of the sensor and confirm that it matches the available power supply in the system. In addition, it is essential to use the correct electrical cables and connectors to ensure proper signal transmission. When connecting sensors to other devices, carefully check the wiring to avoid any incorrect connections that may cause signal errors or device damage.

Maintenance suggestion: For continuous maintenance, sensors should be regularly inspected for any physical signs of damage, such as cracks, dents, or corrosion. Monitor electrical connections for loose wires or damaged connectors, as these issues may cause signal interference or loss. Regularly calibrate sensors according to the manufacturer’s recommended schedule to ensure their long-term accuracy. If any issues are detected, please refer to the detailed troubleshooting guide provided by ABB to promptly identify and resolve the problem.
