ABB PCD231B101 3BHE025541R0101 Product Introduction:
ABB PCD231B101 3HE025541R0101 is for ABB Relief ® The 670 series design is based on microprocessor protection and control IEDs (Intelligent Electronic Devices). Unlike basic relays, this device combines 32-bit DSP processing with IEC 61850-9-2 LE sampling value support, making it equally applicable in traditional substations or fully digital switch stations.
ABB PCD231B101 3HE025541R0101
Its uniqueness lies in its dual plane architecture – independent processing cores simultaneously handle protection algorithms and communication tasks. This means that SCADA operators can retrieve event logs in the event of active device tripping faults without performance degradation. For EPC contractors, the built-in logic editor that complies with the IEC 61131-3 standard eliminates the need for external PLCs in simple automation solutions.
ABB PCD231B101 3HE025541R0101
Technical specifications:
|Model | ABB PCD231B101 3BHE025541R0101
|Protection Function | 67/51V, 81U/81O, 27/59, 50/51
|Analog input | 16 channels (accuracy 0.2%)
|Binary I/O | 24 Programmable|
|Working voltage | 48-250VDC/100-240VAC
|Communication protocols | IEC 61850, DNP3, Modbus
|Working temperature | -40 ° C to+70 ° C
|Moisture resistance | 95% non condensing
|Vibration Compliance | IEC 60255-21-1 Level 2
|Certification | UL 1053, IEC 60255, IEEE C37.90
