ABB LDGRB-01 3BSE013177R1 PROFIBUS-DP fiber link module

Description

ABB LDGRB-01 3BSE013177R1 Product Description:
ABB LDGRB-01 3BSE013177R1 serves as a critical bridge in industrial automation architecture, enabling seamless communication between different parts of the control network. It supports PROFIBUS DP bus, with independent dual bus electrical interfaces and two fiber optic interfaces. This design enables it to provide redundant dual bus structure and fiber optic redundant ring network function, effectively extending the long-distance transmission of data signals.

LDGRB-01 3BSE013177R1

It can smoothly integrate with ABB’s distributed control system (DCS) and programmable logic controller (PLC), as well as other compatible control platforms. The flexible configuration options of this module mean that it can adapt to various network topologies, including point-to-point, star, bus, ring, and hybrid structures. Its built-in diagnostic function can continuously monitor communication status, helping engineers quickly identify and solve any problems, thereby minimizing downtime and ensuring the continuous operation of automation systems.

LDGRB-01 3BSE013177R1

Technical specifications:
Model ABB LDGRB-01 3BSE013177R1
Brand ABB
Type PROFIBUS-DP fiber link module
Working temperature range: 0 ° C to 55 ° C
Interface/Bus PROFIBUS DP, Fiber Optic
Certification CE, RoHS
Support protocol PROFIBUS DP

Contact Us
Phone:+86 16626708626
Email: 3772179818@qq.com
WhatsApp/WeChat:+86 16626708626

LDGRB-01 3BSE013177R1

Main features and advantages:
Choosing ABB LDGRB-01 3BSE013177R1can bring tangible advantages to industrial automation projects. Its fiber optic transmission capability can extend communication distances to over 20 kilometers, eliminating the limitations of traditional cable systems and making the construction of large-scale industrial networks possible. Its redundant design, with dual electrical and fiber optic interfaces, provides backup paths in case of component failure, ensuring the normal operation of critical systems and significantly reducing the risk of unexpected downtime.

The flexibility of this module in network configuration reduces engineering complexity. Whether it’s simple point-to-point connections or complex ring network settings, it can easily adapt to different project needs. The built-in diagnostic function enables maintenance teams to proactively manage the system, reduce maintenance costs, and extend the lifespan of modules. Overall,ABB LDGRB-01 3BSE013177R1 has improved the reliability, scalability, and efficiency of industrial automation systems, bringing long-term value to users.

LDGRB-01 3BSE013177R1

Application areas:
ABB LDGRB-01 3BSE013177R1 has been widely used in multiple industries. In the field of power production, it is used to establish a reliable communication link between remote substations and central control rooms, ensuring seamless monitoring and control of the distribution network even on a large scale. In large petrochemical plants, electromagnetic interference is common. The anti electrical noise capability and fiber optic function of this module can maintain stable communication between various process control units, ensuring safe and efficient production.

For intelligent manufacturing factories that require high-speed and long-distance data transmission between different production lines and quality control systems, it is also an ideal choice. In critical scenarios that require continuous operation, such as water treatment plants and data centers, the redundant functionality of this module ensures uninterrupted operation, guarantees basic services, and minimizes the impact of potential failures on overall system performance.

LDGRB-01 3BSE013177R1

Related product introduction:
ABB LDGSB-01 3BSE018164R1: with stronger data processing capabilities, suitable for data intensive applications.
ABB LDGWB-01 3BSE020698R1: with different fiber interface configurations, suitable for specific network topologies.
ABB LDGCB-01 3BSE018165R1: Designed specifically for PROFIBUS DP communication applications that require higher bandwidth.
ABB LDGAB-01 3BSE018163R1: As an affordable alternative, it has basic fiber link functionality and is suitable for small projects.
ABB LDGDB-01 3BSE018166R1: Includes additional diagnostic functions for deeper system monitoring and maintenance.
ABB LDGEB-01 3BSE018167R1: With a higher operating temperature range, it is suitable for harsh industrial environments.
ABB LDGFB-01 3BSE018168R1: With longer fiber optic transmission distance capability, it is suitable for extremely long distance communication needs.

Installation and maintenance:
Before installing ABB LDGRB-01 3BSE013177R1, it is essential to verify the compatibility of the PROFIBUS DP protocol settings with the existing control system. Ensure that fiber optic connectors and cables meet the specifications of the module to avoid signal loss or connection issues. At the same time, check the power requirements and ensure that the installation environment meets the operating temperature and humidity specifications of the module.

For continuous maintenance, it is necessary to regularly check the fiber optic connectors for signs of damage or dirt, as these factors can affect signal quality. Monitor the diagnostic indicator lights of the monitoring module to promptly detect any communication abnormalities. Regularly update firmware according to ABB’s recommendations to enhance performance and security. Conduct a comprehensive test once a year to verify the communication capability of the module, including data transmission speed, signal integrity, and redundancy functionality.
