ABB DSAI130D 3BSE003127R1 Analog Input Module

Description

The ABB DSAI130D 3BSE003127R1 analog input module is a key component in industrial automation systems, serving as a gateway for converting real-world analog signals into digital data that the control system can understand. It seamlessly integrates with ABB’s control platform (such as AC 800M) and other compatible systems, making it easy to configure within existing architectures.

DSAI130D 3BSE003127R1

This module has 8 isolated analog input channels and can handle multiple signal types, including current and voltage inputs. It has high-precision analog-to-digital conversion function to ensure accurate representation of input signals. The module communicates through PROFIBUS DP fieldbus and can quickly and reliably transmit data to the control system. Its built-in diagnostic function continuously monitors the status of each input channel and detects any faults or abnormal signal conditions. This proactive monitoring capability enables operators to quickly identify and solve problems, minimize downtime, and improve the overall reliability of the automation system. Whether it is a part of a large process control network or a small dedicated automation setup, ABB DSAI130D 3BSE003127R1 plays a crucial role in ensuring accurate data acquisition and system stability.

DSAI130D 3BSE003127R1

Technical specifications:
Model DSAI130D 3BSE003127R1
Brand ABB
Type Analog Input Module
Input voltage range: ± 10 V; current: 0-20 mA, 4-20 mA
Working temperature range -40 ° C to 70 ° C
Installation method: DIN rail installation
Size 105 x 100 x 55 mm
Weight 0.3 kg
Interface/Bus PROFIBUS DP
Compliance with CE and RoHS
Support protocol PROFIBUS DP
Typical power consumption 8 W

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818

DSAI130D 3BSE003127R1

Main features and advantages:
Its high-precision design ensures consistency and accuracy in signal conversion, eliminating the need for frequent calibration and reducing the error range in process control. The 8 isolated input channels provide sufficient capacity for most industrial applications, allowing for simultaneous monitoring of multiple key parameters without the need for additional modules, simplifying system design and reducing engineering costs. The compatibility of this module with various signal types and protocols provides flexibility for system integration, saving time and effort during implementation. The built-in diagnostic function not only helps to quickly detect faults, but also enables predictive maintenance to prevent unexpected system failures and ensure continuous operation. DSAI130D 3BSE003127R1 is designed to withstand harsh industrial environments, capable of withstanding extreme temperatures, vibrations, and electromagnetic interference, ensuring long-term performance and reliability. This makes it a cost-effective choice for industrial applications, providing a high return on investment by minimizing downtime and improving operational efficiency.

Application areas:
In the chemical industry, it is used to monitor process variables such as temperature, pressure, and chemical concentration in reactors and pipelines. Accurate and real-time data collection can achieve precise control of chemical reactions, ensuring product quality and safety.
In power plants, this module is used to measure parameters such as voltage, current, and power factor in electrical systems, which contribute to the efficient operation and maintenance of generators, transformers, and distribution networks.
In the manufacturing industry, it monitors key variables in the production line, such as the speed of the conveyor belt, the position of the robotic arm, and the temperature of the machinery, to achieve active quality control and optimize the production process. Whether in environments that require high-speed data sampling or environments with strict precision requirements, ABB DSAI130D 3BSE003127R1can provide stable performance, making it an ideal choice for various industrial automation applications.

Related products:
ABB DSAI130 3BSE003126R1: Suitable for applications that do not require additional functions of DSAI130D.
ABB DSAI140 3BSE018144R1: Provides 16 analog input channels, offering higher channel capacity for more complex monitoring requirements.
ABB DSAI150 3BSE018145R1: With higher accuracy and faster sampling rate, it is suitable for applications that require high-precision and real-time data acquisition.
ABB DSAI131 3BSE018141R1: With different input signal ranges and configuration options, it is suitable for applications with specific analog signal requirements.
ABB DSAI132 3BSE018142R1: Built in signal conditioning function to improve signal quality, suitable for applications where input analog signals are susceptible to interference.
ABB DSAI133 3BSE018143R1: Supports additional communication protocols, providing more system integration flexibility for diverse automation settings.

Installation and maintenance:
Before installing the ABB DSAI130D 3BSE003127R1 analog input module, it is essential to verify the compatibility of the PROFIBUS DP interface with the existing control system. Ensure that the input voltage supply is within the specified range and that the power supply can meet the power consumption of the module. When installing the module on the DIN rail, make sure to install it firmly and stably to prevent vibration from affecting its performance. Carefully check the wiring connections of each analog input channel to ensure good insulation and correct polarity to avoid signal errors.

For daily maintenance, regularly monitor the status indicator lights on the module to quickly identify any abnormal situations. Regularly inspect connectors for signs of wear, corrosion, or looseness, as these can affect signal integrity. It is also recommended to conduct regular calibration checks to ensure the accuracy of analog-to-digital conversion is guaranteed over time. Updating the firmware of the module according to ABB’s guidelines will ensure that you benefit from the latest features, performance improvements, and security enhancements.
