Description
ABB CI626A 3BSE005029R1 is designed for smooth integration with ABB’s automation systems, but can also be integrated into various industrial control architectures. It has 16 isolated analog input channels and can handle various standard analog input ranges, including 4-20 mA and 0-10 V, making it compatible with most common industrial sensors.
CI626A 3BSE005029R1
This module uses a high-performance analog-to-digital converter to ensure accurate and fast signal conversion. It communicates with the control system through an internal bus to achieve fast data transmission. This module has built-in self diagnostic function, which can continuously monitor the status of each channel and report any faults or abnormal situations in real time. This helps to quickly troubleshoot and reduce downtime. In addition, the module supports hot swapping, which means that modules can be replaced or added while the system is still running, providing great flexibility for system expansion and maintenance.
CI626A 3BSE005029R1
Technical specifications:
Model CI626A 3BSE005029R1
Brand ABB
Type Analog Input Module
Input voltage range 24 VDC (± 20%)
Working temperature range -40 ° C to+70 ° C
Installation method: Rack mounted installation
Dimensions: Depth: 215 mm, Height: 110 mm, Width: 25 mm
Weight approximately 0.2 kg
Interface/Bus ABB proprietary control system bus
Compliance with CE and RoHS
Typical power consumption 2.5 W
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818
CI626A 3BSE005029R1
Main features and advantages:
This module is designed with high reliability, ensuring long-term stable performance even in harsh industrial environments such as strong electromagnetic interference or extreme temperatures. 16 isolated channels reduce the risk of crosstalk between sensors, improve the accuracy of data acquisition, and reduce the possibility of errors in process control. Its hot swappable feature reduces engineering costs as it allows for component replacement without shutting down the entire system, thereby improving the overall availability of the system. The broad working temperature range makes it suitable for deployment in various industrial environments, from extremely cold regions to high-temperature manufacturing plants. The built-in self diagnostic function not only helps to quickly identify faults, but also reduces the time and resources required for maintenance, ensuring long-term cost-effectiveness.
CI626A 3BSE005029R1
Application areas:
In chemical plants, it is used to monitor key process variables such as reactor temperature and pressure, flow rate of chemical raw materials, and pH value of solutions, ensuring the safety and efficiency of chemical production.
In power plants, it plays a crucial role in monitoring the performance of turbines, boilers, and generators by accurately measuring parameters such as steam pressure, temperature, and current, achieving optimal power production and distribution.
In sewage treatment facilities, it helps monitor the quality of incoming and outgoing water by measuring parameters such as turbidity, dissolved oxygen, and chemical concentration, ensuring compliance with environmental regulations. It is capable of processing multiple analog inputs with high precision, making it an ideal choice for applications that require continuous and accurate data acquisition to achieve critical system uptime and process optimization.
Installation and maintenance:
Before installing ABBCI626A 3BSE005029R1, engineers must ensure that the power supply voltage of the system is within the specified 24 VDC (± 20%) range of the module. It is also crucial to verify the compatibility between the control system bus and module interfaces. When connecting sensors, carefully check the analog input range settings on the module to ensure accurate matching with the sensor’s output.
For daily maintenance, regularly check the self diagnostic status indicator lights to quickly identify any faults. Check the physical connections between sensors and modules to ensure they are secure and free from corrosion or damage. Regularly calibrate the module to maintain the accuracy of analog-to-digital conversion. Although the module is designed for long-term reliable operation, following these steps will help ensure that it maintains optimal performance over time.
