ABB AI815 3BSE052604R1 is a versatile 8-channel analog input module designed for smooth interface with ABB’s control platform and backplane systems.
AI815 3BSE052604R1
As a key component in automation architecture, it plays a crucial role in converting physical quantities in the real world, such as voltage, current, temperature, and pressure, into digital signals that can be processed by control systems. Each channel supports multiple analog input types, including 0-10 V DC, 4-20 mA, and thermocouple inputs, providing flexibility for diverse industrial applications.
ABB AI815 3BSE052604R1 is equipped with advanced signal conditioning and filtering functions, effectively reducing noise interference and ensuring clear and accurate signal acquisition. This module also has high-resolution analog-to-digital conversion function, which can accurately measure input values. It supports hot swapping, making it easy to replace or maintain without shutting down the entire system, which is crucial for minimizing downtime in a continuous operating environment. This module communicates smoothly with other devices in the network because it follows industry standard protocols such as Profibus and Modbus, enabling efficient data transmission and integration with existing automation infrastructure.
AI815 3BSE052604R1
Technical specifications:
Model AI815 3BSE052604R1
Brand ABB
Type 8-channel analog input module
Input voltage 24 V DC
Working temperature range -40 ° C to+70 ° C
Installation method: DIN rail installation
Size 110 mm x 100 mm x 60 mm
Weight 0.7 kg
Interface/Bus Profibus, Modbus
Compliance with CE and RoHS
Supported protocols Profibus DP, Modbus RTU, Modbus TCP
Typical power consumption 10 W
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
AI815 3BSE052604R1
Main features and advantages:
This module is designed for long-term reliability and can withstand harsh industrial environments, reducing module replacement frequency and related maintenance costs. Its high-resolution analog-to-digital conversion function ensures the consistency and accuracy of data acquisition, which is crucial for maintaining the accuracy of the control system. This accuracy helps prevent errors in process control, thereby improving product quality and reducing waste.
The flexibility of input type support and the ability to configure each channel independently make it easy to integrate into existing systems, thereby reducing engineering costs. The hot plug function improves system availability, allowing for quick repairs or upgrades without interrupting ongoing operations. The built-in diagnostic function is displayed through LED status indicators, allowing engineers to quickly identify and troubleshoot any issues, further improving maintenance efficiency and reducing downtime. Overall, ABB AI815 3BSE052604R1helps improve productivity, operational stability, and cost-effectiveness in industrial automation settings.
AI815 3BSE052604R1
Application areas:
In manufacturing, it is used to monitor and control various parameters on the production line, such as temperature, pressure, and flow rate, to ensure optimal process conditions and product quality. For example, in an automotive assembly plant, it can accurately measure the pressure of the hydraulic system or the temperature of the engine during testing, thereby achieving precise control and quality assurance.
In the field of power generation, this module plays a key role in monitoring the power generation process. It can measure parameters such as voltage, current, and power factor in power plants, providing real-time data for grid stability and efficient power distribution. In renewable energy facilities such as wind farms and solar power plants, it helps monitor the performance of turbines and solar panels to ensure maximum energy output.
In the chemical processing industry, safety and accuracy are crucial, and ABB AI815 3BSE052604R1 is used to monitor key process variables such as chemical concentration and reaction temperature. Its accurate signal acquisition capability helps prevent dangerous situations and ensure compliance with strict safety regulations.
AI815 3BSE052604R1
Related products:
ABB AI810 3BSE018199R1- a basic 8-channel analog input module suitable for simple applications that prioritize cost-effectiveness.
ABB AI830 3BSE022151R1- Provides higher precision and more advanced signal processing capabilities, suitable for applications that require precise measurements, such as research laboratories or high-end manufacturing.
ABB AI845 3BSE030562R1- a high-density 16 channel analog input module suitable for applications that require processing large amounts of input signals, such as large industrial control systems.
ABB AI850 3BSE051012R1- equipped with enhanced network security features, suitable for applications where data security is critical, such as critical infrastructure or government related projects.
ABB AI820 3BSE018200R1- a compact 4-channel analog input module suitable for space constrained automation settings.
ABB AI860 3BSE051013R1- Designed specifically for high-speed data acquisition, suitable for applications with rapidly changing input signals, such as high-speed manufacturing processes or dynamic testing environments.
ABB AI870 3BSE051014R1- Provides improved noise immunity and isolation capabilities for applications where signal integrity is critical in noisy industrial environments.
Installation and maintenance:
Before installing ABB AI815 3BSE052604R1, it is essential to verify the compatibility of the interface/bus and supported protocols with your existing control system. Ensure that communication settings meet the requirements of your network to avoid data transmission issues. Check the input voltage requirements and ensure that your electrical infrastructure can provide a stable 24V DC power supply. When installing the module on a DIN rail, make sure there is enough space around it for proper ventilation, as heat dissipation is crucial for maintaining optimal performance.
For continuous maintenance, please regularly check the module for any signs of physical damage, such as cracks or loose connections. Monitor the LED status indicator to quickly identify any potential issues, such as communication errors or channel failures. Regularly clean the module to remove dust and debris, which may affect its performance over time. In addition, it is recommended to conduct regular calibration checks to ensure the accuracy of analog input measurements.
