ABB 5SHX1060H0003 High-Current High-Voltage IGBT Module (Half-Bridge Configuration)

Description

5SHX1060H0003

The ABB 5SHX1060H0003 serves as a critical power switching component in high-power industrial systems, utilizing advanced IGBT technology to precisely control the flow of electricity—enabling seamless AC-DC or DC-AC conversion, as well as voltage regulation for sensitive equipment. It integrates seamlessly into ABB’s broader power ecosystem, working in tandem with ABB’s ACS6080 medium-voltage drives, PCS6000 energy storage inverters, and grid converters. Unlike standard IGBT modules, it features ABB’s next-generation trench-gate IGBT chip design, which reduces switching losses by up to 20% compared to older planar-gate designs.

5SHX1060H0003

This not only boosts overall system efficiency but also minimizes heat generation, a key factor in extending component life. The module’s robust packaging includes a ceramic-insulated baseplate that ensures excellent electrical isolation (essential for high-voltage safety) while facilitating efficient heat transfer to external heat sinks, even when operating at its full current rating of 1000 A. Additionally, it supports integration with ABB’s Ability™ Power Platform, allowing engineers to monitor real-time parameters like junction temperature, current, and voltage—enabling proactive maintenance and preventing unplanned downtime.

Main features and advantages:

Choosing the ABB 5SHX1060H0003 delivers significant long-term value beyond basic power switching. It’s built to withstand harsh industrial conditions, with a rugged housing that resists vibration (up to 55 Hz), thermal cycling (from -40 °C to +150 °C), and exposure to industrial contaminants like dust and oil. This durability reduces the need for frequent replacements, lowering the total cost of ownership over the module’s lifespan. The module’s high current rating (1000 A) and voltage tolerance (6500 V DC) make it highly versatile, eliminating the need to source multiple modules for different high-power applications—simplifying inventory management and cutting down on engineering time spent on system design. Its low switching losses translate to substantial energy savings: in a large water treatment plant using ABB ACS6080 drives, the ABB 5SHX1060H0003 can reduce annual energy consumption by up to 10% compared to less efficient IGBT modules, resulting in significant cost savings. Moreover, its compatibility with existing ABB medium-voltage systems means minimal retrofitting is required during upgrades, avoiding the expense of replacing entire control setups.

Application fields:

The ABB 5SHX1060H0003 excels in high-power, high-reliability applications across various industries. In utility-scale energy storage, it’s used to switch high-voltage DC power between large battery banks and the grid, ensuring stable power flow and supporting grid frequency regulation—critical for integrating renewable energy sources like wind and solar. In heavy industry, it’s a key component in medium-voltage drives for cement kilns and steel rolling mills, handling the high current loads needed to control large motors with precision. This not only improves production efficiency but also reduces wear on mechanical components, extending their lifespan. In grid infrastructure, it’s integrated into grid-tied converters that connect distributed energy resources to the main grid, maintaining voltage stability even during peak demand periods. In all these environments, the module’s ability to operate at extreme temperatures and handle voltage spikes up to 8500 V ensures critical system uptime, even in the most challenging conditions.

Related products:

ABB 5SHX1260H0003– Higher current rating (1200 A) for ultra-high-power applications like large industrial compressors.

ABB 5SHX1045H0003– Lower voltage tolerance (4500 V DC) for cost-sensitive medium-power systems such as small-scale energy storage.

ABB 5SHX1060H0004– Enhanced-isolation version for systems with strict safety requirements, such as nuclear power auxiliary drives.

ABB 5SHX1060H0002– Older generation module; compatible with legacy ABB drives but lacks the latest trench-gate IGBT technology.

ABB 5SHX1060H0005– Fast-switching variant for high-frequency applications like high-speed train traction converters.

ABB 5SHX1060H0006– Compact design (190 mm x 110 mm) for space-constrained systems such as marine power converters.

ABB 5SHX1060H0007– Extended-temperature model (-50 °C to +160 °C) for extreme environments like arctic oil rig power systems.

Installation and maintenance:

Before installing the ABB 5SHX1060H0003, verify compatibility with your existing high-voltage system: ensure the drive, inverter, or converter’s voltage and current ratings align with the module’s specs (6500 V DC, 1000 A) to prevent overloads. Prepare the heat sink by cleaning its surface with a lint-free cloth and isopropyl alcohol—any debris will increase thermal resistance, leading to overheating. Torque the mounting screws to ABB’s recommended 15 N·m using a torque wrench; under-tightening can cause poor heat transfer, while over-tightening may damage the module’s baseplate. Update the system’s control software (such as ABB Ability™ Power Platform) to the latest version to access all diagnostic features.

For ongoing maintenance, inspect the module’s terminal connections quarterly for signs of corrosion or loosening, which can cause arcing and module failure. Monitor junction temperature via the control software—if temperatures exceed 135 °C, check the heat sink’s cooling fan (if installed) and clean any accumulated dust. Perform a yearly insulation resistance test using a 2500 V megohmmeter to ensure the module’s electrical isolation remains intact.
