ABB 3HNA006146-001 Robotic Control System Power Supply

Description

3HNA006146-001

The ABB 3HNA006146-001 functions as a regulated power supply module, designed specifically to meet the power demands of ABB’s robotic control systems. It mounts directly to the internal power bay of ABB IRC5 and OmniCore E10/E20 controllers, converting incoming AC line voltage (100-240 V AC) into the stable DC voltages required by the controller’s core components—including processors, communication modules, and servo interface modules like the ABB 3HAC14550-408A. Unlike generic industrial power supplies, it’s engineered to deliver precise voltage regulation (±2% tolerance for 24 V DC output), ensuring consistent performance even when the input voltage fluctuates—critical for maintaining the accuracy of robotic motion commands. The module also features built-in power protection mechanisms: overvoltage shutdown, short-circuit prevention, and surge suppression.

These safeguards activate in under 5 milliseconds, shielding the controller’s sensitive electronics from damage caused by power spikes (common in factory environments with heavy machinery) or accidental short circuits. Additionally, the ABB 3HNA006146-001 includes thermal management features, such as a low-noise cooling fan and heat-dissipating aluminum housing, which prevent overheating during extended operation—essential for maintaining reliability in high-temperature factory settings.

Main features and advantages:

Choosing the ABB 3HNA006146-001 delivers long-term value by enhancing reliability, reducing maintenance costs, and extending the lifespan of ABB robotic systems. Its native compatibility with ABB controllers eliminates the need for voltage adapters or custom wiring, cutting integration time by up to 30% compared to third-party power supplies. For example, an automotive plant upgrading 50 IRC5 controllers can standardize on the ABB 3HNA006146-001, ensuring consistent power delivery across all robotic cells and simplifying spare parts management. The module’s high power efficiency (85% at full load) also reduces energy consumption—over a year of 24/7 operation, a single module uses approximately 1,200 kWh less than a generic power supply with 75% efficiency, translating to $150+ in annual energy savings per robot cell.

Durability is another key advantage: the ABB 3HNA006146-001 is built to withstand the rigors of factory environments, including electrical noise (up to 100 V/m EMI immunity) and mechanical vibration (up to 3 g). This robustness ensures the module operates reliably even in harsh settings like metalworking facilities, where welding equipment generates intense electrical interference. Its built-in protection features also extend the mean time between failures (MTBF) of ABB robotic controllers by 40%—for instance, if a power surge occurs, the module shuts down instantly, preventing damage to the controller’s processor that could cost $2,000+ to repair. Additionally, the module’s diagnostic LED indicators (for input voltage, output status, and fault conditions) simplify troubleshooting: maintenance teams can quickly identify power-related issues without specialized tools, reducing mean time to repair (MTTR) from hours to minutes.

Application fields:

The ABB 3HNA006146-001 is deployed across industries that rely on consistent robotic performance. In automotive manufacturing, it powers IRC5 controllers for IRB 6700 welding robots, ensuring uninterrupted operation of assembly lines that produce 60+ cars per hour. In electronics production, it supplies stable power to OmniCore E10 controllers for IRB 120 pick-and-place robots, preventing power-related errors that would ruin microchip assemblies. In logistics, it’s used in OmniCore E20 controllers for IRB 760 palletizing robots, ensuring 24/7 operation of warehouse automation systems. It also excels in collaborative robotics: paired with ABB YuMi cobots, it provides the steady power needed for safe human-robot interaction, as voltage fluctuations could cause unexpected cobot movements. Across all these use cases, the module’s ability to operate in temperatures up to 50°C and handle varying input voltages (100-240 V AC) makes it suitable for global deployment—from factories in North America (120 V AC) to Europe (230 V AC).

Related products:

ABB 3HNA006146-002 – High-output power supply (24 V DC / 15 A, 5 V DC / 8 A) for robot controllers with additional modules (e.g., Ethernet communication cards).

ABB 3HNA006146-003 – Compact power supply (150 mm x 60 mm x 180 mm) for space-constrained robot cells (e.g., small electronic assembly workstations).

ABB 3HNA006146-004 – Wide-temperature power supply (-10°C to 60°C) for robots in extreme environments (e.g., cold-storage food processing, hot foundries).

ABB 3HNA006146-005 – Redundant power supply module, designed for 1+1 redundancy in mission-critical systems (e.g., nuclear power plant robotic handlers).

ABB 3HNA006145-001 – Legacy power supply for older ABB S4 controllers, with an upgrade path to 3HNA006146-001 for IRC5/OmniCore compatibility.

ABB 3HNA006146-006 – Low-noise power supply (≤40 dB) for cleanrooms or labs where robotic systems operate near sensitive equipment.

ABB 3HNA006146-007 – DC-input power supply (24-48 V DC) for mobile robotic systems (e.g., autonomous guided vehicles with integrated robots).

ABB 3HNA006146-008 – Smart power supply with Ethernet monitoring, enabling remote tracking of voltage, current, and temperature via ABB RobotStudio.

Installation and maintenance:

Before installing the ABB 3HNA006146-001, verify compatibility with your ABB controller model (IRC5 or OmniCore E10/E20) and ensure the controller’s internal power bay has sufficient space (check dimensions: 150 mm x 80 mm x 200 mm). Confirm the incoming AC voltage matches the module’s input range (100-240 V AC) and install a dedicated circuit breaker (16 A recommended) to protect against overcurrent. Update the controller firmware to at least version 6.0—older firmware may not recognize the module’s diagnostic features, limiting fault detection capabilities. Also, inspect the controller’s power connectors for corrosion or damage; clean or replace connectors if needed to ensure a secure electrical connection with the ABB 3HNA006146-001.

For maintenance, check the module’s LED indicators monthly: a steady green “INPUT” light confirms valid AC input, a steady green “OUTPUT” light signals normal DC output, and a red “FAULT” light indicates issues like overvoltage or overheating (refer to the service manual for fault codes). Every three months, clean the module’s cooling fan and air vents with compressed air (low pressure, <30 psi) to remove dust—clogged vents cause overheating, which reduces the module’s lifespan. Annually, measure the output voltages with a calibrated multimeter to verify regulation (24 V DC ±2%, 5 V DC ±3%); if voltages drift beyond tolerance, replace the module to prevent controller damage. In high-vibration environments (e.g., stamping plants), tighten the module’s mounting screws quarterly to avoid loose connections that could cause intermittent power loss. Never attempt to repair the ABB 3HNA006146-001—replace it with a genuine ABB module to maintain controller compatibility and safety.
