ABB 3BHE039203R0101 GVC736CE101 Control Board

Description

The ABB 3BHE039203R0101 GVC736CE101 control board is located in the central control position in industrial automation systems and is the key to achieving precise control and stable operation of the entire system. It is designed specifically for ABB’s specific series of large-scale control systems, and can work closely with various sensors, actuators, and upper monitoring systems to build a complete automation control system.

3BHE039203R0101 GVC736CE101

This control board is equipped with a high-performance multi-core processor, which has powerful data processing and computing capabilities. It can quickly analyze and process real-time data from various links of the system, and accurately output control instructions based on preset control logic and algorithms, achieving precise control of motor speed, equipment start stop, process parameters, etc. Its rich interface resources, including high-speed digital communication interfaces, analog signal interfaces, etc., support multiple industrial communication protocols such as Profibus, Ethernet/IP, etc., which can easily achieve seamless integration and data interaction with different devices, greatly improving the compatibility and scalability of the system. At the same time, the control board is equipped with advanced fault diagnosis and redundancy design, which can monitor its own operating status in real time. Once an abnormality is detected, it can quickly switch to the redundant module to continue working, ensuring uninterrupted operation of the system and significantly improving its reliability and fault tolerance.

3BHE039203R0101 GVC736CE101

Technical specifications:
Model Number 3BHE039203R0101 GVC736CE101
Brand ABB
Type Control Board
Input Voltage 24V DC（±10%）
Processor High – performance multi – core processor
Memory 2GB Flash, 1GB SRAM
I/O Ports 16 digital inputs, 12 digital outputs, 8 analog inputs, 4 analog outputs
Communication Protocols Profibus, Ethernet/IP, Modbus TCP
Operating Temp Range -20°C to +60°C
Storage Temp Range -40°C to +85°C
Humidity 5% – 95% RH, non – condensing
Protection Class IP20
Dimensions 200mm x 150mm x 40mm
Weight 1.2kg
Compliance CE, RoHS

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818

3BHE039203R0101 GVC736CE101

Main features and advantages:
Its excellent reliability comes from high-quality electronic components and rigorous manufacturing processes, coupled with advanced redundancy design, which can operate stably in complex electromagnetic interference environments and a wide temperature range, significantly reducing equipment downtime caused by control board failures and ensuring production continuity. The high-precision control capability enables the system to achieve precise adjustment of production process parameters, with deviations controlled within a very small range, meeting the extremely high requirements for product quality in production processes, effectively improving product qualification rates and production efficiency. Fast data processing and response speed enable it to respond promptly to unexpected situations in the production process, such as sudden load changes, equipment abnormalities, etc., quickly adjust control strategies, and avoid production accidents. In addition, the easy integration and debugging feature of the control board significantly shortens the deployment cycle of new systems and the upgrade and transformation time of existing systems, reduces project implementation costs, and creates higher economic benefits for enterprises.

Application areas:
In the power industry, it can be used for generator control systems in power plants to accurately adjust parameters such as generator speed and voltage, ensuring stable power output;
In the metallurgical industry, automated control systems applied to steel production lines can accurately control key parameters such as rolling speed and pressure of rolling mills, improving steel quality and production efficiency;
In the chemical industry, precise control of temperature, pressure, flow rate and other parameters used in chemical reaction vessels ensures that chemical reactions occur under optimal conditions, guaranteeing production safety and product quality.

Related products:
ABB 3BHE039203R0201 GVC736CE102: Enhanced in processor performance and memory capacity, suitable for large industrial projects that require higher data processing capabilities and more complex control logic.
ABB 3BHE039202R0101 GVC736CE100: Suitable for small and medium-sized industrial scenarios with relatively simple control function requirements and limited budget.
ABB 3BHE039203R0102 GVC736CE103: Optimized communication functionality, supports more communication protocols and higher data transmission rates, making it easy to integrate with complex industrial networks.
ABB 3BHE039203R0103 GVC736CE104: Enhanced anti-interference capability and protection level, more suitable for use in harsh industrial environments such as high dust and strong electromagnetic interference.
ABB 3BHE039204R0101 GVC736CE105: Added specific functional modules such as high-speed counting, position control, etc., suitable for automated production lines with special control function requirements.
ABB 3BHE039203R0104 GVC736CE106: Improved in heat dissipation design, capable of long-term stable operation in high-temperature environments, suitable for high-temperature industries such as metallurgy and glass manufacturing.

Installation and maintenance:
Before installing the ABB3BHE039203R0101 GVC736CE101 control board, engineers need to carefully check whether the input power supply voltage is within the range of 24V DC (± 10%), ensure that the power supply is stable and without fluctuations, and avoid damaging the control board due to abnormal voltage. At the same time, it is necessary to check whether the installation space meets the size requirements of 200mm x 150mm x 40mm for the equipment, and ensure that the installation location is well ventilated to facilitate heat dissipation of the control board. In addition, it is necessary to confirm that the interface of the control board matches the specifications and types of the connecting cables to ensure that the electrical connection is firm and reliable. In daily maintenance, regularly check the status indicator lights on the control board to determine whether the equipment is running normally based on the status of the indicator lights; Check if the wiring terminals are loose to prevent poor contact from causing abnormal signal transmission or control command failure; Regularly clean the dust on the surface of the control board to avoid affecting heat dissipation and electrical performance due to dust accumulation. Perform functional tests on the control board at regular intervals to verify its control accuracy, response speed, and communication functionality. If any abnormalities are found, the detailed user manual and fault diagnosis guide provided by ABB can be used to quickly locate and solve the problem.
