ABB 3BHB030310R0001 Control Power Supply Module (ACS880 Drive)

Description

3BHB030310R0001

The ABB 3BHB030310R0001 sits at the heart of the ACS880 drive’s power architecture, acting as a bridge between the main AC supply and the drive’s control system. It mounts directly inside the ACS880 drive chassis, connecting to the drive’s internal backplane to draw input power (110-240V AC) and convert it to a stable 24V DC output—this eliminates the need for external power supplies, simplifying installation and reducing wiring complexity.

3BHB030310R0001

What distinguishes this module is its robust protection features: it includes overvoltage, undervoltage, and short-circuit protection, which shield the ACS880’s sensitive electronics from damage during power anomalies. Additionally, the ABB 3BHB030310R0001 supports real-time status monitoring via the drive’s HMI (Human-Machine Interface) or connected control system, allowing engineers to track voltage output and detect potential issues (like a failing capacitor) before they cause a shutdown. Unlike generic power supplies, it’s engineered specifically for the ACS880’s power demands, ensuring seamless compatibility and optimal performance.

3BHB030310R0001

Main features and advantages:

Choosing the ABB 3BHB030310R0001 delivers tangible, long-term value that goes beyond basic power conversion. Engineered for industrial ruggedness, it withstands the harsh conditions common in heavy industries—including electrical noise from nearby motors, temperature swings, and vibration—ensuring consistent performance where generic power supplies would fail. This reliability translates to fewer drive shutdowns: in a mining operation, for example, a single unplanned conveyor stop can cost thousands in lost production, making the module’s stability a critical cost-saving asset. Its broad input voltage range (110-240V AC) also eliminates the need for voltage transformers when deploying ACS880 drives across global facilities, reducing equipment costs and simplifying international projects.

For maintenance teams, the ABB 3BHB030310R0001 reduces workload and troubleshooting time. Its integration with the ACS880’s diagnostic system means technicians don’t have to manually test power supplies with multimeters—they can access voltage readings and fault codes directly from the drive’s HMI, pinpointing issues like a failing input circuit in minutes. The module’s plug-and-play design also speeds up replacements: when maintenance is needed, technicians can swap it out in under 20 minutes without disassembling the entire drive, minimizing downtime. Long-term, its compatibility with the ACS880 series ensures future-proofing—if you upgrade your ACS880 drive to a higher-power model or add new control features, the ABB 3BHB030310R0001 will continue to support the drive’s needs, avoiding the expense of replacing power components.

3BHB030310R0001

Application fields:

The ABB 3BHB030310R0001 is deployed in industries where reliable drive operation is non-negotiable. In mining, it powers ACS880 drives for belt conveyors that transport ore—its ability to handle voltage dips from grid fluctuations ensures the conveyors don’t stop mid-operation, preventing bottlenecks in the mining process. In water and wastewater treatment plants, it supplies power to ACS880 drives controlling pump systems; here, consistent control power is critical to maintaining water flow and avoiding overflows or treatment disruptions. In manufacturing, it’s used with ACS880 drives for plastic extrusion machines, where stable power ensures precise temperature and speed control—this prevents defective products and reduces material waste. Across all these use cases, the module’s rugged design stands up to harsh conditions: dust in mining facilities, humidity in water plants, and mechanical vibration in manufacturing—making it a trusted choice for critical system uptime. Whether the need is 24/7 continuous operation (water treatment) or resistance to electrical interference (manufacturing), the ABB 3BHB030310R0001 delivers the consistency engineers depend on.

Related products:

3BHB030310R0002 – Higher-output version (7A current) for ACS880 drives with additional control electronics (e.g., safety modules).

3BHB030310R0000 – Lower-output version (3A current) for compact ACS880 models (e.g., ACS880-01 micro drives).

3BHB021400R0002 – ABB power supply module for older ACS800 drives (compatible with legacy systems upgrading to ACS880).

3BHB030311R0001 – Isolated version of the 3BHB030310R0001 (for environments with extreme electrical noise, like welding shops).

3BHB030310R0003 – Extended-temperature version (-25°C to 65°C) for outdoor or cold-storage applications (e.g., refrigerated warehouse conveyors).

3BHB013089R0001 – Redundant power supply module (works with 3BHB030310R0001) for mission-critical ACS880 setups (e.g., power plant pumps).

3BHB030310R0004 – High-voltage input version (200-480V AC) for industrial facilities with three-phase control power.

3BHB030312R0001 – Smart version with IoT connectivity (sends real-time power data to cloud platforms for predictive maintenance).

Installation and maintenance:

Before installing the ABB 3BHB030310R0001, first confirm compatibility with your ACS880 drive model: it’s designed for ACS880-04, ACS880-06, and ACS880-11 series drives, but check the drive’s technical manual to ensure it fits the “Control Power Slot” (slot 3 or 4, depending on drive size). Always follow lockout/tagout (LOTO) procedures—disconnect the ACS880 drive from the main power supply and verify no voltage remains in the chassis before opening the drive cover. Inspect the module’s connectors for damage (e.g., bent pins) before installation, as damaged connectors can cause intermittent power issues. Also, ensure the drive’s internal cooling fan is functioning: the ABB 3BHB030310R0001 relies on the drive’s airflow to stay within operating temperatures, so a faulty fan can lead to overheating and module failure.

For ongoing maintenance, monitor the module’s status via the ACS880’s HMI weekly: check for “Control Power Fault” or “Voltage Out of Range” alerts, which indicate issues like a failing rectifier. Every three months, inspect the module’s heatsink (if equipped) for dust buildup—use compressed air to clean it, as dust blocks heat dissipation and shortens lifespan. Every six months, verify the 24V DC output with a calibrated multimeter: readings outside the ±1% tolerance range signal a need for calibration or module replacement. Avoid using the module with unfiltered input power, as excessive noise can degrade performance—if your facility has poor power quality, install an external line filter (ABB recommends model 1SFA896106R1000) to protect the ABB 3BHB030310R0001.
