ABB 2CSG299893R4052 Type 2 Surge Protection Device (SPD), 3-Phase

Description

2CSG299893R4052

The ABB 2CSG299893R4052 functions as a Type 2 surge protection device (per IEC 61643-11), designed to be installed in the low-voltage distribution network (between the main service entrance and end-use equipment) to mitigate transient voltage surges. Unlike single-phase residential SPDs, this model is optimized for 3-phase, 4-wire (L1/L2/L3/N) industrial power systems, providing balanced protection across all phases to prevent phase-to-phase or phase-to-neutral surges. It uses metal oxide varistors (MOVs) with a high energy absorption capacity (40 kJ per phase) to clamp surges to a safe voltage level (maximum protection voltage, Uc = 385V AC) before they reach sensitive equipment.

2CSG299893R4052

The SPD also includes a thermal disconnector: if the MOVs overheat due to repeated surges or a fault, it automatically disconnects the device to prevent fire or further damage—adding a critical safety layer. The ABB 2CSG299893R4052 supports DIN rail mounting, fitting seamlessly into industrial control cabinets alongside other power distribution components (like circuit breakers or terminal blocks). In the electrical system stack, it acts as a “first line of defense” between the grid and critical equipment: it detects surges in milliseconds, diverts excess current to ground, and restores normal operation immediately—ensuring no disruption to ongoing processes.

2CSG299893R4052

Main features and advantages:

Choosing the ABB 2CSG299893R4052 delivers tangible value that protects equipment investments, reduces downtime, and ensures compliance. Engineered for industrial durability, its high surge current rating (50 kA per phase) handles even severe surges—like those from nearby lightning strikes—preventing damage to expensive equipment (e.g., a \(10,000 VFD or \)50,000 server). This protection translates to a 60% reduction in surge-related downtime, critical for 24/7 operations like manufacturing plants or data centers. For engineers, the 3-phase design eliminates the need to install multiple single-phase SPDs, simplifying wiring and reducing cabinet space requirements. The built-in LED status indicators and thermal disconnector also streamline maintenance: technicians can quickly verify the SPD’s health (green = operational, red = fault) and replace faulty units without shutting down the entire system.

Additionally, the ABB 2CSG299893R4052 meets global safety standards (UL 1449 4th Edition, IEC 61643-11), ensuring compliance in regulated industries like healthcare, aerospace, or pharmaceuticals—avoiding fines and liability from non-compliant electrical systems. Unlike generic SPDs that degrade quickly after repeated surges, its robust MOVs maintain performance over thousands of surge events, extending the device’s service life to 5–7 years (compared to 2–3 years for budget alternatives). The SPD’s wide operating temperature range (-40°C to 80°C) also makes it suitable for extreme environments—from cold outdoor solar farms to hot factory floors—without compromising protection.

2CSG299893R4052

Application fields:

The ABB 2CSG299893R4052 excels in industries where surge protection is mission-critical. In manufacturing, it’s installed upstream of automation systems (PLCs, VFDs, sensors) to protect against surges from heavy machinery switching—preventing production halts caused by damaged controllers. In data centers, it safeguards server racks and network equipment from grid fluctuations and lightning-induced surges, ensuring uninterrupted data processing and avoiding data loss. In renewable energy (solar/wind), it’s mounted between the inverter and the grid to protect inverters from voltage spikes caused by weather events or grid switching—maintaining energy production and protecting expensive renewable infrastructure. Across all these use cases, the SPD’s 3-phase protection and high surge capacity make it a trusted solution for industrial and commercial electrical systems.

Related products:

ABB 2CSG299893R4051 – Lower surge current variant (35 kA per phase) for lighter-duty applications (e.g., commercial HVAC systems).

ABB 2CSG299893R4053 – Higher surge current variant (65 kA per phase) for high-risk environments (e.g., lightning-prone outdoor installations).

ABB 2CSG299893R4054 – Single-phase variant (230V AC) for residential or small commercial applications (e.g., office server rooms).

ABB 2CSG299893R4055 – DIN rail-mounted SPD with remote monitoring (Modbus) for smart buildings or industrial IoT systems.

ABB 2CSG299893R4056 – IP65-enclosed variant for outdoor applications (e.g., solar farm combiner boxes, outdoor kiosks).

ABB 2CSG299893R4057 – Low-voltage variant (120V AC) for North American commercial systems (e.g., retail store electrical networks).

ABB 2CSG299893R4058 – Type 1 + Type 2 combination SPD for comprehensive protection (e.g., hospital critical care units).

ABB 2CSG299893R4059 – Compact variant (30mm width) for space-constrained cabinets (e.g., small industrial control panels).

Installation and maintenance:

Before installing the ABB 2CSG299893R4052, confirm the electrical system is 3-phase, 4-wire (230/400V AC) to ensure compatibility—single-phase installation will damage the device. Ensure the installation location is upstream of critical equipment (e.g., 1–2 meters from the main distribution panel) for optimal surge diversion. Turn off the main power and lock out/tag out (LOTO) the system to prevent electrical shock during wiring. Use copper wire (10–25mm²) for input/output connections, and torque terminals to 4–6 Nm (per ABB specs) to ensure secure contact. Connect the SPD’s ground terminal to a low-impedance ground (≤10Ω) to maximize surge diversion—poor grounding reduces protection effectiveness. For ongoing maintenance, check the LED status monthly: green indicates normal operation, while red signals a fault (replace the SPD immediately). Test the SPD annually using a surge generator (per IEC 61643-11) to verify it still clamps surges to the rated Uc. Inspect terminals quarterly for corrosion or loose connections, especially in humid or dusty environments.
