The ABB 1TGB302003R0003 terminal block serves as a bridge and hub in electrical systems. It is exquisitely designed to facilitate reliable connection of various electrical equipment and cables, ensuring stable transmission of current and signals.
1TGB302003R0003
This terminal block is made of high-quality conductive and insulating materials, with excellent electrical performance and mechanical strength. Its unique plug-in design makes wiring and maintenance operations more convenient and efficient, allowing engineers to quickly connect and replace cables. In terms of system integration, it can perfectly adapt to various electrical control equipment from ABB, such as PLC control cabinets, frequency converters, etc. It is also compatible with other brands of equipment that meet standard specifications, effectively improving the flexibility of system construction. In addition, the terminal block is equipped with comprehensive overload protection and short circuit protection functions. When there is an abnormality in the circuit, the current can be quickly cut off to avoid equipment damage and safety accidents, ensuring the stable operation of the entire electrical system.
1TGB302003R0003
Technical specifications:
Model Number 1TGB302003R0003
Brand ABB
Type Wiring Terminal Block
Rated Voltage 1000 V AC/DC
Rated Current 125 A
Number of Positions 24
Connection Type Screw – connection, Plug – in
Insulation Material Thermoplastic
Conductive Material Copper with surface treatment
Operating Temp Range -40°C to +85°C
Protection Class IP20
Compliance CE, RoHS
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818
1TGB302003R0003
Main features and advantages:
Its high rated voltage and current design can meet the connection requirements of high-power electrical equipment and adapt to industrial application scenarios of different scales. High quality insulation materials and strict manufacturing process enable it to have excellent insulation performance and anti-aging ability, which can operate stably in harsh industrial environment for a long time and reduce equipment downtime caused by terminal strip failure. The convenient plug-in connection method and reasonable layout design not only reduce installation difficulty, but also greatly improve the maintenance efficiency of the electrical system, saving manpower and time costs. The comprehensive protection function adds multiple safety locks to the electrical system, effectively reducing safety risks and safeguarding the safety production of enterprises.
1TGB302003R0003
Application areas:
In the power industry, it is commonly used in power distribution systems in substations and distribution rooms to achieve reliable connections between cables and electrical equipment, ensuring stable power transmission;
In automotive manufacturing automation production lines, it is used to connect various sensors, controllers, and actuators to ensure accurate transmission of signals and power between production equipment, and maintain efficient operation of the production line;
In the field of building electrical engineering, it can be applied to building power distribution systems, lighting control systems, etc., to achieve reasonable distribution and safe connection of electrical circuits, providing guarantee for the normal electricity consumption of buildings.
1TGB302003R0003
Related products:
ABB 1TGB302004R0003: Added more wiring positions, suitable for large industrial projects that require connecting more cables and more complex electrical nodes.
ABB 1TGB302002R0003: Simplified design with fewer wiring positions, more suitable for small electrical systems that are cost sensitive and have relatively simple connection requirements.
ABB 1TGB302003R0004: Optimized protection level, with better dust and moisture resistance, suitable for use in harsh environments such as humidity and high dust.
ABB 1TGB302003R0005: Improved conductivity and reduced contact resistance, suitable for connecting precision electrical equipment with extremely high requirements for current transmission efficiency.
ABB 1TGB302003R0006: Using special flame-retardant insulation materials, it can provide more reliable electrical connection security in places with high fire safety requirements, such as data centers, hospitals, etc.
Installation and maintenance:
Before installing the ABB 1TGB302003R0003 terminal block, engineers need to carefully check whether the cable specifications match the rated current and voltage of the terminal block, in order to avoid the risk of poor connection or overload caused by cables that are too thin or too thick. At the same time, it is necessary to ensure that the installation location is dry and ventilated, meets the environmental requirements of IP20 protection level, and prevent the performance of the terminal block from being affected by environmental factors. When wiring, strictly follow the wiring specifications to ensure that the screw tightening force is moderate, avoiding poor contact or damage to the cable.
In daily maintenance, regularly check whether the wiring terminals of the terminal block are loose, whether the insulation material is damaged or aged, monitor the temperature of the terminal block through infrared temperature measurement and other methods, timely detect abnormal heating conditions, and determine whether there are problems such as poor contact. If any problems are found, troubleshooting and repair can be carried out according to the product manual provided by ABB.
