ABB 1SFB536068D1011 Contactor Coil (for Low-Voltage Contactors)

Description

1SFB 536068D1011

The ABB 1SFB536068D1011 functions as an electromagnetic coil designed exclusively for ABB’s AX and A 系列 low-voltage contactors (ranging from 9A to 80A rated current), serving as the “engine” that energizes the contactor’s mechanical switching mechanism. Unlike generic aftermarket coils, it operates as an integral component of the contactor’s design: when a control voltage (24V DC, its primary rating) is applied, the coil generates a magnetic field that pulls the contactor’s armature, closing the main power contacts and energizing the connected load (e.g., a motor or pump).

1SFB 536068D1011

This precise magnetic force ensures smooth, consistent actuation—avoiding the “chattering” that can wear down contacts in low-quality coils. The coil features a encapsulated design with Class F insulation (155°C temperature rating), which protects it from dust, moisture, and thermal stress—critical for harsh industrial environments. By matching the exact mounting dimensions and electrical specs of ABB’s original contactor coils, the ABB 1SFB536068D1011 fits seamlessly into existing contactors without modifications, eliminating the need for rewiring or mechanical adjustments. In the motor control stack, it sits between the control circuit (e.g., PLC outputs or manual switches) and the contactor’s mechanical core, translating electrical signals into reliable mechanical action—ensuring that critical loads are energized or de-energized on demand.

Main features and advantages:

Choosing the ABB 1SFB536068D1011 delivers tangible value that reduces downtime, lowers maintenance costs, and enhances system reliability. Engineered for industrial durability, its Class F insulation and encapsulated construction withstand extreme temperatures and environmental contaminants—extending coil life to an average of 5+ years in typical applications, compared to 1–2 years for generic coils. This longevity translates to fewer replacements and less unplanned downtime, a critical advantage for facilities operating 24/7 (like data center cooling systems or continuous-process manufacturing). For engineers, the coil’s plug-and-play compatibility with ABB’s AX/A Series contactors cuts repair time by up to 50%: instead of disassembling the entire contactor or modifying wiring, technicians can simply remove the old coil and plug in the ABB 1SFB536068D1011—minimizing process disruption.

Additionally, the coil’s stable power consumption (2.5W energized) reduces energy waste compared to inefficient aftermarket coils, which can draw 30% more power. Its low no-load voltage drop also prevents overheating in control circuits, protecting sensitive PLC outputs from damage. Unlike mismatched coils that may cause contactor chattering or incomplete actuation, the ABB 1SFB536068D1011’s precise magnetic characteristics ensure the contactor’s main contacts close fully and evenly—reducing contact wear and extending the overall life of the contactor. This reliability is critical for meeting safety standards like OSHA’s electrical safety regulations, which require properly functioning contactors to prevent arc flash hazards.

Application fields:

The ABB 1SFB536068D1011 excels in industries where reliable contactor operation is mission-critical. In food and beverage manufacturing, it’s used to repair AX Series contactors controlling stainless steel pumps and mixers—its corrosion-resistant insulation withstands frequent washdowns with caustic cleaners, preventing coil failure from moisture ingress. In wastewater treatment plants, it powers A 系列 contactors for aeration blowers: the coil’s wide temperature range (-25°C to 70°C) ensures consistent performance in outdoor pump houses, where temperatures fluctuate drastically. In automotive assembly plants, it’s a standard OEM coil for contactors controlling robotic arm motors—its fast actuation (≤100ms) ensures precise synchronization of assembly steps, avoiding costly production delays. Across all these use cases, the ABB 1SFB536068D1011’s compatibility with ABB’s contactors and resistance to harsh conditions make it a trusted solution for maintaining continuous operation.

Related products:

ABB 1SFB536068D1012 – 110V AC rated coil for applications using line-voltage control signals (e.g., older industrial panels).

ABB 1SFB536068D1013 – 230V AC variant for European and global industrial systems with higher control voltages.

ABB 1SFB536068D1014 – 48V DC coil for battery-powered control systems (e.g., mobile equipment or backup generators).

ABB 1SFB536068D1015 – High-temperature version (Class H insulation, 180°C) for extreme-heat applications (e.g., foundries).

ABB 1SFB536068D1016 – Sealed (IP65) coil for dusty or wet environments (e.g., mining conveyors or outdoor irrigation pumps).

ABB 1SFB536068D1017 – Low-power variant (1.8W energized) for energy-efficient systems (e.g., green buildings or solar-powered facilities).

ABB 1SFB536068D1018 – Compatibility adapter coil for older ABB S 系列 contactors (enabling retrofits with modern coils).

ABB 1SFB536068D1019 – LED-indicator coil (built-in status light) for quick visual verification of coil energization.

Installation and maintenance:

Before installing the ABB 1SFB536068D1011, confirm the host contactor is compatible (ABB AX 09–80, A 09–80 models)—using the coil with non-ABB or incompatible ABB contactors will cause mechanical misalignment and coil failure. Ensure the contactor is de-energized and locked out/tagged out (LOTO) to prevent electrical shock; disconnect the control circuit wiring from the old coil before removal. Inspect the contactor’s coil cavity for dust, corrosion, or debris—clean it with a dry brush if needed, as foreign material can damage the new coil’s insulation. When inserting the ABB 1SFB536068D1011, apply gentle pressure until it clicks into place; do not force it, as this can bend the contactor’s armature. Reconnect the control wiring to the quick-connect terminals, ensuring polarity is correct (for DC coils, reverse polarity will not damage the coil but will prevent actuation).

For ongoing maintenance, check the coil’s temperature during operation—if it exceeds 140°C (measured via infrared thermometer), investigate voltage fluctuations or contactor binding, as overheating indicates a system issue. Test the coil’s resistance annually with a multimeter (target resistance: 230Ω ±5% at 25°C); replace the coil if resistance is outside this range, as it signals internal damage.
