8206-TI-IS Intrinsically Safe Temperature and Pressure Input Module
Sale!
8206-TI-IS Intrinsically Safe Temperature and Pressure Input Module
The 8206-TI-IS is an intrinsically safe temperature and pressure input module, specifically developed for use in explosive atmospheres. It is part of a series of high-performance modules designed to integrate seamlessly into safety instrumented systems (SIS) and distributed control systems (DCS) that operate in ATEX and IECEx classified areas.
Model 8206-TI-IS
Brand EMERSON
Type Intrinsically Safe Temperature and Pressure Input Module
Power Supply 24V DC (intrinsically safe isolated)
Operating Temperature -40°C to +80°C
Mounting DIN rail (35mm) with quick-release clips
Dimensions 120mm x 85mm x 60mm (W x H x D)
Weight 380 grams
Interfaces 6 x temperature inputs (compatible with thermocouples, RTDs), 4 x pressure inputs (4-20mA), 1 x Ethernet, 1 x HART port
Certifications ATEX II 1G Ex ia IIC T5 Ga, IECEx Ex ia IIC T5 Ga, UL Class I Div 1 Groups A-D
Cooling Natural convection
Environmental Rating IP20 (when mounted in enclosure)
The 8206-TI-IS is an intrinsically safe temperature and pressure input module, specifically developed for use in explosive atmospheres. It is part of a series of high-performance modules designed to integrate seamlessly into safety instrumented systems (SIS) and distributed control systems (DCS) that operate in ATEX and IECEx classified areas.
8206-TI-IS
This module fits into the control system architecture as a critical interface between field sensors that measure temperature and pressure and the main control unit. What makes the 8206-TI-IS valuable is its ability to accurately process and transmit temperature and pressure data from hazardous areas to non-hazardous control rooms without compromising safety. For engineers designing systems in space-limited hazardous locations, its compact size allows for easy installation in crowded control cabinets. It is compatible with a wide range of temperature sensors (such as thermocouples and RTDs) and pressure transducers, making it a versatile option for various industrial applications.
8206-TI-IS
Main features and advantages:
The 8206-TI-IS boasts exceptional accuracy in data acquisition, which is crucial for precise process control. It can measure temperature with an accuracy of ±0.1°C and pressure with an accuracy of ±0.05% of full scale, ensuring that the control system receives reliable and precise data. This high level of accuracy allows for tighter control of industrial processes, reducing waste and improving product quality.
In terms of hardware design, the 8206-TI-IS features a durable, corrosion-resistant housing made from stainless steel, which can withstand exposure to harsh chemicals, moisture, and extreme temperatures. Its intrinsic safety design limits electrical energy to levels that cannot ignite flammable substances, with certifications for Zone 0/1 (gas) and Zone 20/21 (dust) environments. It also has advanced noise filtering capabilities, ensuring that the measured data is not affected by electrical interference common in industrial settings.
8206-TI-IS
Technical specifications:
Model 8206-TI-IS
Brand EMERSON
Type Intrinsically Safe Temperature and Pressure Input Module
Power Supply 24V DC (intrinsically safe isolated)
Operating Temperature -40°C to +80°C
Mounting DIN rail (35mm) with quick-release clips
Dimensions 120mm x 85mm x 60mm (W x H x D)
Weight 380 grams
Interfaces 6 x temperature inputs (compatible with thermocouples, RTDs), 4 x pressure inputs (4-20mA), 1 x Ethernet, 1 x HART port
Certifications ATEX II 1G Ex ia IIC T5 Ga, IECEx Ex ia IIC T5 Ga, UL Class I Div 1 Groups A-D
Cooling Natural convection
Environmental Rating IP20 (when mounted in enclosure)
