60M500-05-00 Next Generation Robot Controller

60M500-05-00 is a next-generation robot controller designed to drive high-performance motion systems in harsh industrial environments. As the flagship model of the M500 series, it serves as the “central nervous system” for robotic arms, gantry systems, and hybrid servo pneumatic actuators. Built on a real-time operating system (RTOS), it ensures that task execution jitter is below 100 microseconds, which is crucial for applications where time errors can lead to catastrophic failures.

Model  60M500-05-00
Brand BENTLY
Type Robot Controller/Multi axis Motion Controller
Power supply 24 V DC (± 20%)+12 V DC backup power supply
Working temperature -20 ° C to+60 ° C
Installation method: Panel installation/Rack installation (19 inch standard)
Dimensions 482 millimeters (width) x 266 millimeters (height) x 130 millimeters (depth)
Weight 8.5 kilograms
Communication protocols EtherCAT, PROFINET, OPC UA over TSN, CANopen
Supports a maximum of 32 axes (synchronous, supports six degree of freedom robots)
Control mode includes torque, speed, position, and compliance control
Safety certification SIL3, PL e, ISO 10218 (robot safety)
Cooling method: forced air cooling (detachable fan module)
Protection level: front panel IP65, rear panel IP20
I/O capacity 1024 digital I/O (expandable through bus)



Description

60M500-05-00 is a next-generation robot controller designed to drive high-performance motion systems in harsh industrial environments. As the flagship model of the M500 series, it serves as the “central nervous system” for robotic arms, gantry systems, and hybrid servo pneumatic actuators. Built on a real-time operating system (RTOS), it ensures that task execution jitter is below 100 microseconds, which is crucial for applications where time errors can lead to catastrophic failures.

60M500-05-00

60M500-05-00

This controller can be seamlessly integrated into the robot ecosystem of [brand], including servo drives, vision systems, and safety PLCs, forming a unified automation platform. For engineers, its value lies in modular design: 60M500-05-00supports hot swappable I/O modules and can be upgraded on-site without downtime. Its dual core processor architecture uses one core for motion planning (such as inverse kinematics of a six degree of freedom robot) and the other core for logic control (such as safety interlocking, sensor fusion), ensuring parallel processing efficiency. Whether it’s renovating a 20-year-old old stamping line or deploying state-of-the-art collaborative robot units, the 60M500-05-00 controller can provide the scalability and reliability required for 24/7 production environments.

60M500-05-00

60M500-05-00

Main features and advantages:
The significant feature of 60M500-05-00 is its raw computing power: the 1.5 GHz quad core processor enables it to execute 50000 motion instructions per second, supporting the most complex robot trajectories. Its advanced torque control algorithm can shorten cycle time by up to 20% in stamping and placement applications, while predictive vibration suppression can reduce tool wear by 30%. The robust aluminum casing (IP65 protection level) of this controller can withstand high humidity, dust, and oil mist, making it suitable for foundries, welding units, and other harsh environments.

In terms of connectivity, it supports cutting-edge protocols such as OPC UA over TSN (Time Sensitive Network) and can be seamlessly integrated into IIoT platforms to achieve real-time performance monitoring through cloud dashboards. This module provides 128 MB of user programmable memory, which can accommodate custom algorithms for adaptive control, such as dynamic load compensation in material handling robots.

Long term reliability is guaranteed through redundant power input design (24 V DC main power supply+12 V DC backup power supply) and a wide operating temperature range (-20 ° C to+60 ° C). The independent testing certification has a mean time between failures (MTBF) of 150000 hours, and the built-in self diagnostic function can predict component fatigue (such as capacitor degradation) before a fault occurs. Engineers praise its “hot redundancy” capability, which seamlessly switches to backup controllers during maintenance without interrupting production.

60M500-05-00

60M500-05-00

Technical specifications:
Model  60M500-05-00
Brand BENTLY
Type Robot Controller/Multi axis Motion Controller
Power supply 24 V DC (± 20%)+12 V DC backup power supply
Working temperature -20 ° C to+60 ° C
Installation method: Panel installation/Rack installation (19 inch standard)
Dimensions 482 millimeters (width) x 266 millimeters (height) x 130 millimeters (depth)
Weight 8.5 kilograms
Communication protocols EtherCAT, PROFINET, OPC UA over TSN, CANopen
Supports a maximum of 32 axes (synchronous, supports six degree of freedom robots)
Control mode includes torque, speed, position, and compliance control
Safety certification SIL3, PL e, ISO 10218 (robot safety)
Cooling method: forced air cooling (detachable fan module)
Protection level: front panel IP65, rear panel IP20
I/O capacity 1024 digital I/O (expandable through bus)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

60M500-05-00

60M500-05-00

Application areas:
In heavy industrial environments that require both precision and strength, the 60M500-05-00 controller is a reliable solution for executing critical automation tasks. This controller is designed specifically for industries such as automotive stamping plants, aerospace component manufacturing, and large-scale material handling systems, and can meet the unique challenges of high load and high-speed operation. For example, in the production of car body in white, it can manage the synchronous operation of stamping machines weighing over 100 tons and six axis robots, ensuring millisecond level coordination during sheet metal forming and part transfer processes. It can handle ultra-high torque commands (up to 500 Nm) and real-time force feedback, making it indispensable in applications where mechanical stress and position accuracy are equally important.

In the field of aerospace manufacturing, the 60M500-05-00 controller is proficient in controlling CNC milling machines used for processing complex titanium alloy fuselage components. Its advanced multi axis interpolation capability (supporting up to 32 axis synchronization) enables vibration free machining at feed rates exceeding 10 meters per minute, while maintaining tolerances within ± 5 micrometers. Engineers have also deployed it in logistics automation, such as high-speed palletizing systems for warehouses, where it can coordinate triangular robots to process over 1200 packages per hour with zero misalignment. As a key driver of industrial automation, the60M500-05-00 controller has been optimized for heavy-duty load control systems, becoming the preferred choice for applications that require both powerful power and precise operation.

60M500-05-00

60M500-05-00

Related products:
60M500-10-00- Supports 64 axes and is equipped with FPGA acceleration for AI driven motion planning.
The 60D800-05-00-800 W servo drive module is optimized for direct pairing with the 60M500-05-00 in heavy-duty robot applications.
60S300-00- Safety Expansion Module, adding dual channel emergency stop and axis specific safety restrictions.
60V120-00-3D Vision Camera System, pre calibrated to achieve real-time path correction with 60M500-05-00.
60H190-00-19 inch touchscreen human-machine interface, pre installed M500 series robot programming kit.
60C900-00- Status monitoring module, providing real-time analysis of motor health and controller performance.
60P480-00-480 W redundant power supply, certified for use with 60M500-05-00 in safety critical applications.



Installation and maintenance:
Install 60M500-05-00in a climate control cabinet with a dedicated cooling zone to ensure cooling of heat sensitive components. Ensure that all signal cables use shielded twisted pair and are routed away from high-power cables to comply with EMC standards. For rack installation, use shock-absorbing brackets in stamping intensive environments to prevent connector fatigue. Before powering on, verify that the firmware version of the controller matches the driver and sensor firmware to avoid compatibility issues.

Daily maintenance should include checking the airflow of the fan module every quarter (replacing it every 24 months as a preventive measure), as well as calibrating feedback equipment (such as encoders and rotary transformers) annually. Utilize the built-in ‘health dashboard’ to monitor key indicators such as CPU utilization, network latency, and thermal capacity. In high dust environments, clean the front panel vents with anti-static wipes every month. For software maintenance, schedule a semi annual exercise program review to optimize cycle time and eliminate outdated routines.
