5SHX2645L0004 Product Introduction:
5SHX2645L0004 is a high-performance industrial power electronic module produced by ABB, belonging to the integrated gate commutated thyristor (IGCT) series products. Widely used in the fields of medium and high voltage variable frequency speed regulation systems, power transmission, renewable energy generation, and industrial drives, it has become an important component in the field of power electronics with its advanced technology and reliable performance.
5SHX2645L0004 is a high-performance industrial power electronic module produced by ABB, belonging to the integrated gate commutated thyristor (IGCT) series products. Widely used in the fields of medium and high voltage variable frequency speed regulation systems, power transmission, renewable energy generation, and industrial drives, it has become an important component in the field of power electronics with its advanced technology and reliable performance.
Technical specifications:
Product model: 5SHX2645L0004 3BHL000389P0104
Manufacturer: ABB
Product type: IGCT module
Repetitive peak reverse voltage VDRM: 4500 V
On state average current ITAVM: 2645 A
On state surge current ITSM: 40000 A
Gate trigger current IGT: 200 mA
Gate trigger voltage VGT: 3 V
Working temperature Tj: -40 ° C to+125 ° C
Storage temperature Tstg: -40 ° C to+150 ° C
Packaging type: Press pack
Terminal type: crimping type
contact us:
Mobile:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
Main features and advantages:
The 5SHX2645L0004 thyristor module is suitable for applications that require high current processing capability. The specific current value may vary depending on the product version or application requirements, but it usually has a high current carrying capacity. It can handle high voltage and is suitable for use in high voltage environments. It combines the advantages of insulated gate bipolar transistors (IGCT) and integrated gate driver circuits, with low on state voltage drop and improved module efficiency. Stable operation in high temperature environment, with excellent thermal management performance, ensuring that the module will not be damaged due to overheating during long-term operation. Designed to be sturdy and capable of withstanding harsh conditions in industrial environments such as vibration, shock, and humidity.
Application areas:
5SHX2645L0004 3BHL000389P0104 is used for power conversion and control of high-power DC power sources, such as high-voltage DC transmission systems. Applied in the starting and control system of large motors in motor control, providing precise power regulation and control. In UPS systems, it is used to provide stable power output and ensure that critical equipment can continue to operate in the event of power outages. The 5SHX2645L0004 3BHL000389P0104 module is used in power quality management to improve power quality, reduce power loss, and enhance the efficiency and stability of the power system
Installation and maintenance:
Preparation before installation: Ensure that the 5SHX2645L0004 module operates within the allowable temperature range (usually -20 ℃ to+60 ℃), avoiding performance degradation or damage caused by high temperature or humid environments. The installation environment should be clean and free from strong vibrations to prevent dust or mechanical impact from affecting internal components. Adequate heat dissipation space should be reserved around to avoid unstable performance or shortened lifespan due to overheating.
Strictly follow the equipment manual to connect the power and signal lines, avoiding misconnections or short circuits. It is recommended to use shielded cables to reduce electromagnetic interference.
Maintenance suggestion:
Regularly inspect the 5SHX2645L0004 casing for any damage, deformation, or signs of overheating. Check if the power, signal, and grounding wires are loose or aged, and if necessary, re tighten or replace them. Clean the dust on the cooling fan or fins to ensure good heat dissipation. Check the operating status through device indicator lights or monitoring software to promptly detect any abnormalities. Regularly conduct load tests to ensure stable operation of the equipment under rated conditions. If the device malfunctions, first cut off the power, and then troubleshoot the problem according to the fault code or indicator light prompt.
