350092 136188-02 Multi channel Industrial Monitoring Module

Description

350092 136188-02 is a multi-channel industrial monitoring module in the BENTLY 3500 series, designed specifically for harsh industrial applications. As the interface between on-site sensors (such as accelerometers and thermocouples) and control systems, this module can provide real-time insights into equipment health status, support data-driven decision-making, optimize equipment operating time, and reduce maintenance costs.

350092 136188-02

The module supports 4 configurable input channels (IEPE, thermocouple,…) LVDT）， Can be seamlessly integrated into distributed control systems (DCS) or edge computing platforms. Its modular architecture allows engineers to mix vibration, temperature, and displacement measurements in a single unit, simplifying hardware deployment in complex environments. For system integrators, native support for EtherNet/IP, Profinet, and Modbus TCP ensures compatibility with older PLCs and modern IIoT ecosystems, while their ATEX/IECEx certification simplifies deployment in explosive or hazardous areas.

350092 136188-02

Main features and advantages:
Extreme environmental tolerance
IP68 protection level enclosure: dustproof and can be immersed in water (10 meters deep, 24 hours), suitable for underwater applications or high-pressure flushing environments.
Corrosion resistant coating: Nickel plated aluminum chassis and conformal coated PCB can resist salt spray, chemicals, and humidity (ISO 9227 standard).
High precision data collection
4 synchronous channels: 24 bit ADC, with a sampling rate of up to 10 kHz per channel, capable of simultaneously monitoring vibration and temperature.
Advanced signal processing: Built in Fast Fourier Transform (FFT), envelope analysis, and trend tracking to identify fault modes (such as bearing defects and misalignment) with 98% accuracy.
Flexible connectivity
Dual Ethernet ports: support ring topology structure, achieve redundant network connections, and ensure uninterrupted data transmission at remote or offshore sites.
Wireless ready: Optional Wi Fi/Bluetooth module (sold separately) for remote diagnosis without physical access.
Long term reliability
Self diagnostic system: continuously monitors the health status of sensors, power stability, and thermal performance, and issues potential problem alerts to operators through SNMP traps.
10-year lifecycle support: ensuring the availability of spare parts and firmware updates, providing future security for industrial investments.

350092 136188-02

Technical specifications:
Model350092 136188-02
Brand BENTLY
Type: Multi channel industrial monitoring module
Four configurable input channels (IEPE/TC/LVDT)
Sampling rate of up to 10 kHz per channel
Working temperature -40 ° C to+125 ° C
Power supply 18-32 V DC (dual redundant input)
Dimensions: 180 mm (width) x 100 mm (height) x 90 mm (depth)
Installation method: DIN rail, panel installation or flange installation
Certified ATEX/IECEx (Zone 1/21), CE, UL, IP68
Environmental level IEC 60068-2-6 (vibration), IEC 60068-2-27 (impact)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

350092 136188-02

Application areas:
In offshore platforms, salt spray corrosion and continuous mechanical vibration threaten equipment integrity. 350092 136188-02 can monitor the operating status of pumps, compressors, and rotating machinery. Its IP68 rated enclosure and corrosion-resistant coating ensure stable operation in salt spray and humid environments. In metallurgical plants, modules can withstand high temperatures (+125 ° C continuous operation) from rolling mills and furnaces, and monitor shaft vibration, bearing temperature, and structural stress in real time through high-temperature sensors. For heavy equipment manufacturers, this module can capture dynamic data during rigorous testing, verify the durability of engineering machinery prototypes, and ensure their compliance with safety and performance standards.

By combining robust hardware design with advanced data analysis, 350092 136188-02 enables the industry to detect anomalies in a timely manner before faults escalate into significant losses. Its performance in these scenarios highlights its value as a key asset for industrial automation under harsh conditions.

350092 136188-02

Related products:
350092 136189-02-8 channel version, suitable for monitoring large mechanical equipment
350093 136188-02- Low power model, supports solar charging, suitable for remote assets
350040M-EX – Explosion proof proximity probe interface module
350022M-IP68- Single channel vibration monitoring module, suitable for underwater applications
350033-RED – Redundant Communication Module, Suitable for Fault Safety Systems

Installation and maintenance:
Before installation:
For offshore or underwater applications, ensure that all cable seals are sealed to IP68 standard torque and tested using a pressure attenuation system.
In high-temperature areas, use mineral insulated copper-clad (MICC) cables and route the wiring through heat-resistant conduits.
Use ping testing to verify network latency and ensure real-time data transmission meets application requirements (such as critical control loops<10 ms).
maintain:
Monthly: Check for signs of aging on the sealing components of the casing; If cracks or compression deformation are found, replace the O-ring.
Quarterly: Conduct sensor health checks through the module’s web interface to identify drift (such as thermocouple calibration drift>2 ° C).
Every year: Perform a comprehensive system reset and firmware update, clear accumulated error logs, and activate new features.
Every six months: calibrate using a vibration table and temperature chamber according to traceable standards, and record the results to meet ISO compliance requirements.
