350091 Multi channel status monitoring module

Description

350091 is a state-of-the-art multi-channel status monitoring module designed to provide unparalleled accuracy in measuring mechanical parameters of rotating and reciprocating machinery.

350091

This module is designed for scalability and can be integrated into distributed control systems (DCS) or independent monitoring racks, supporting multiple input channels such as vibration, temperature, or position sensors. Its modular architecture allows engineers to mix and match input types (such as accelerometers, proximity probes) within a single unit, thereby reducing hardware complexity and wiring costs. For system integrators, their plug and play compatibility with [brand] monitoring software simplifies the debugging process, while open protocols ensure interoperability with third-party SCADA systems.

350091

Main features and advantages:
Ultra precision data collection
350091 is equipped with a synchronous sampling function of a 24 bit analog-to-digital converter, ensuring minimal noise and distortion in the vibration waveform. This accuracy is crucial for detecting minor anomalies in gearboxes or turbines, as even a 0.1% deviation from baseline may indicate an impending failure.

Robust industrial design
This module is designed to withstand extreme conditions, with a metal casing and a protection level of IP65 (dustproof/waterproof). It operates within a temperature range of -40 ° C to+85 ° C. Its impact resistance (up to [X] g) and electromagnetic interference (EMI) immunity make it suitable for installation near high-voltage equipment or seismic zones.

Flexible connectivity
350091 natively supports Profibus DP, EtherNet/IP, and Modbus TCP, making it easy to integrate with legacy PLCs and modern cloud based IoT platforms. Engineers can configure custom data streams for real-time dashboards or historical recording systems, enabling cross functional teams to collaborate and optimize performance.

Long term reliability
The built-in self diagnostic system continuously monitors the hardware health status and marks before issues such as loose connections or sensor drift affect measurements. Redundant power input and hot swappable modules ensure zero downtime during maintenance, while a 10-year lifecycle guarantee minimizes the risk of obsolescence in long-term projects.

350091

Technical specifications:
Model350091
Brand BENTLY
Type multi-channel status monitoring module
Communication protocols Profibus DP, EtherNet/IP, Modbus TCP
Power supply 18-32 V DC (redundant input)
Installation method: DIN rail or rack installation
Certified CE, UL, ATEX (Zone 2) IECEx
Environmental protection level IP65, IEC 61000-6-2 (electromagnetic compatibility)

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

Application areas:
In refineries, 350091 is used to monitor high-speed compressors and pumps, detecting early signs of imbalance or bearing degradation through real-time vibration analysis. Its ability to interface with legacy and modern control systems makes it an ideal choice for retrofitting old factories while seamlessly integrating with cutting-edge Industrial Internet of Things (IIoT) platforms.
In power plants, it ensures the safe operation of turbines by continuously measuring shaft displacement, temperature, and axial position, allowing engineers to proactively adjust maintenance plans and avoid catastrophic failures. The automotive assembly line utilizes its precision to monitor robot welding machines and conveyor systems, ensuring consistent performance and reducing defect rates.

Related products:
350092- High temperature variant (up to+125 ° C), suitable for furnace applications
350093- Wireless module with built-in LTE, suitable for remote assets
350040M – Proximity Probe Interface Module (Complementary Sensor Pairing)
350022M – Dual channel vibration monitor, suitable for basic machinery
350033- TSI (Total Station Interface) module, suitable for process integration

Installation and maintenance:
Considerations before installation:
Install the module in a grounded and climate controlled cabinet to prevent moisture and extreme temperature effects.
Use shielded twisted pair cables to connect sensors to reduce electromagnetic interference, and try to control the signal line length within [X] meters as much as possible.
Use surge protectors to verify the stability of power supply, especially in areas with unstable power grid.
Maintenance suggestion:
Perform a visual inspection every quarter to identify loose connectors or corrosion, and use a torque wrench to secure the DIN rail mounting components.
Run self diagnostic tests through the network interface of the module every month to check the accuracy and communication latency of the analog-to-digital converter (ADC).
Schedule an annual calibration of a certified laboratory to maintain measurement traceability, especially in compliance driven industries such as pharmaceuticals.
Update the firmware quarterly to access new diagnostic algorithms and security patches, first testing the updates in a sandbox environment.
