The Bentley 3500/46M-03-00 is a high-performance six channel monitoring module designed to meet the high-precision monitoring needs of complex industrial environments as an important member of the Bentley 3500 series monitoring system.
350046M-03-00
It can seamlessly connect with various types of sensors such as eddy current sensors, acceleration sensors, speed sensors, etc., and can simultaneously collect multidimensional data such as vibration, displacement, acceleration, etc. of the equipment. The module is equipped with advanced signal processing algorithms and high-speed data processing chips, which not only enable high-precision filtering, amplification, and digital conversion of raw signals, but also support advanced functions such as real-time spectrum analysis and envelope demodulation. It can accurately identify abnormal states such as imbalance, misalignment, and bearing faults during equipment operation.
350046M-03-00
Main features and advantages:
This module supports flexible programming through 3500 rack configuration software. Users can freely combine the functions of each channel according to their actual monitoring needs, achieving diversified monitoring tasks such as radial vibration monitoring, axial displacement monitoring, differential expansion monitoring, etc. At the same time, Bentley 3500/46M-03-00 has powerful alarm and data transmission capabilities, which can compare the processed data with the user’s preset multi-level alarm thresholds in real time. Once the parameters are abnormal, it will immediately issue an alarm through various methods such as relay output and digital communication, and quickly transmit key data to the central control system for engineers to make timely decisions.
Its multi-channel parallel monitoring and advanced data analysis capabilities can achieve comprehensive and accurate evaluation of equipment operating status, significantly advance fault warning time, help enterprises transform from passive maintenance to active maintenance, and effectively reduce unplanned downtime and maintenance costs. The highly integrated design and standardized communication interface of the module enable it to easily integrate into existing automation systems, significantly reducing engineering integration time and cost. In addition, the sturdy and durable hardware design and anti-interference ability ensure that the Bentley3500/46M-03-00 can operate stably in harsh industrial environments such as high temperature, high dust, and strong electromagnetic interference, providing reliable support for long-term production of enterprises.
350046M-03-00
Technical specifications:
Model 3500/46M-03-00
Brand Bentley Nevada
Type six channel multifunctional monitoring module
Number of input channels: 6 channels
Input signal types include eddy current sensor signal, acceleration sensor signal, velocity sensor signal, etc
Measure parameters such as vibration amplitude, frequency, displacement, acceleration, phase, etc
Real time spectrum analysis, envelope demodulation, trend analysis, and digital filtering in signal processing technology
Analog output range 4-20mA (multi parameter optional output)
Digital output relay output (multi-level alarm), Modbus TCP, Profibus and other communication protocol outputs
Working voltage 24VDC
Working temperature range -30 ° C to+65 ° C
Installation method: Rack installation (compatible with 3500 series standard rack)
Interface/Bus 3500 series internal bus, supporting industrial communication protocols such as Modbus TCP, Profibus, Ethernet/IP, etc
Compliance with international standards such as CE and RoHS
Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com
350046M-03-00
Application areas:
In the power industry, it can be used to monitor key parameters such as vibration and displacement of large steam turbine generators, ensuring the stable operation of power generation equipment;
In the petrochemical industry, multi-dimensional monitoring is carried out on rotating equipment such as compressors and pumps to timely detect potential equipment failures and ensure safe and continuous chemical production;
In the metallurgical industry, comprehensive status monitoring of equipment such as rolling mills and fans can be achieved, optimizing equipment operating parameters, and improving product quality and production efficiency.
350046M-03-00
Related products:
Bentley 3500/40M: A more basic monitoring module suitable for applications with relatively less complex monitoring requirements. Compared to 3500/42M 176449-02, it may have fewer features or a lower level of functionality.
Bentley 3500/44M: an enhanced module with more channels or advanced signal processing capabilities. This model is very suitable for applications that require more comprehensive monitoring of sensors or deeper analysis of equipment conditions.
350046M-03-00
Installation and maintenance:
Before installing Bentley3500/46M-03-00, a comprehensive compatibility check must be conducted. Ensure that the sensor type connected to the module is appropriate and the signal characteristics meet the input requirements of the module. Verify if there is sufficient installation space in the 3500 series rack and check power compatibility to ensure stable operation.
For continuous maintenance, it is necessary to regularly check the module for any signs of physical damage, especially in harsh environments. Check the connection between the sensor and the 3500 series system to ensure it is secure. It may be necessary to perform regular calibration of the module once a year or every six months based on the criticality of the application to maintain its high-precision measurement capability.
