3500/22 Interface Module

Description

The Bentley 3500/22 interface module is a key component in the well-known Bentley 3500 monitoring system, designed specifically for industrial applications that require continuous and accurate data acquisition. It plays a crucial role as an interface module in the data flow between various monitoring elements. This module is commonly used in scenarios where static data related to mechanical operating conditions needs to be collected.

3500-22

In large manufacturing plants, power generation facilities, and petrochemical refineries, the 3500/22 can be installed to collect important data for equipment such as turbines, generators, and pumps. It can interface with various sensors and other modules in the 3500 system to collect data such as vibration level, temperature, and pressure. These data will then be further transmitted within the system for processing and analysis, enabling operators to make informed decisions regarding equipment maintenance and operation.

3500-22

Technical specifications:
Model 3500/22
Brand Bentley Nevada
Type interface module (for static data collection)
The input signal type is compatible with the output signals of various sensors used for mechanical health monitoring
Working temperature range -30 ° C to+65 ° C
Installation method: Rack mounted installation (designed specifically for 3500 series racks)
The interface/bus communicates with other 3500 system components through a dedicated bus within the system
Compliance with relevant industry standards, such as electromagnetic compatibility and environmental adaptability standards
Support proprietary protocols within the Bentley 3500 system to achieve seamless data transmission

Contact Us
Phone:+86 16626708626
WeChat/WhatsApp:+86 16626708626
Email: 3772179818@qq.com

3500-22

Main features and advantages:
Its design ensures stable data collection even in harsh industrial environments, and can withstand factors such as vibration, temperature fluctuations, and electromagnetic interference. This reliability reduces the risk of unexpected equipment failures, thereby reducing high production interruption costs. The compatibility of this module with the 3500 system simplifies the integration process and reduces engineering costs during system setup or expansion. In addition, the accurate data it provides helps implement preventive maintenance strategies, ensuring the long-term performance of the monitored equipment by detecting early signs of wear or failure.

3500-22

Application areas:
In power plants, it is used to monitor the health status of turbines and generators. By continuously collecting static data on parameters such as vibration and temperature, it helps predict potential faults and maintain continuous power generation.
In the petrochemical industry, pumps and compressors are critical equipment, and their performance is monitored by 3500/22 to ensure smooth operation in processes that typically operate 24 hours a day without interruption. In the manufacturing industry, especially in industries involving high-speed rotating machinery, this module enables operators to track equipment conditions, optimize production efficiency and product quality.

Related products:
Bentley 3500/22M: Enhanced version, capable of collecting static and transient data. Suitable for applications that require more comprehensive datasets, such as conducting in-depth fault diagnosis during device startup or shutdown.
The interface modules in the Bentley 3500/20:3500 series have different data processing capabilities or interface characteristics for simpler monitoring settings.

Installation and maintenance:
Before installing the Bentley3500/22, make sure it is compatible with existing 3500 system components. Check the bus connection and ensure that the input and output signals of the module match the connected sensors and other modules. In addition, it is necessary to verify whether the rack where the module is installed has sufficient space and power supply.
For continuous maintenance, it is necessary to regularly check the module connections for signs of wear or looseness. Check the LED indicator lights (if any) to ensure proper functioning. Conducting regular functional testing once a year can help identify any potential issues early, ensure the module continues to perform at its best, and contribute to the effectiveness of the entire mechanical monitoring system.
