The 0100-77037 is a high-performance analog input module designed to convert real-world physical signals—like temperature, pressure, and flow—into digital data that control systems can process. It’s part of a modular automation platform, seamlessly integrating with both traditional PLCs and modern industrial IoT (IIoT) networks, making it ideal for both retrofits and new installations.
Model 0100-77037
Brand AMAT
Type Analog Input Module (Multi-Signal)
Power Supply 24 V DC (1.2A max)
Operating Temperature -40°C to +70°C
Mounting DIN Rail (35mm)
Dimensions 65mm x 125mm x 80mm (WxHxD)
Weight 0.4 kg
Interfaces 8 analog inputs (supports thermocouples, RTDs, 4-20mA, 0-10V), HART, Ethernet/IP
Certifications CE, UL, ATEX, IECEx, FDA 21 CFR Part 11
Cooling Passive (no fans)
Environmental Rating IP20 (with optional IP65 enclosure)
Signal Resolution 16-bit
Update Rate 10 ms per channel
The 0100-77037 is a high-performance analog input module designed to convert real-world physical signals—like temperature, pressure, and flow—into digital data that control systems can process. It’s part of a modular automation platform, seamlessly integrating with both traditional PLCs and modern industrial IoT (IIoT) networks, making it ideal for both retrofits and new installations.
0100-77037
In a control system architecture, the0100-77037 acts as the “sensory hub,” capturing analog signals from field devices and conditioning them to eliminate noise, ensuring the central controller receives clean, reliable data. What sets it apart for engineers is its ability to handle a wide range of signal types—from thermocouples and RTDs to 4-20mA transducers—eliminating the need for multiple specialized modules. Integrators value its plug-and-play compatibility with third-party systems, reducing integration time and minimizing errors in complex setups.
0100-77037
Main features and advantages:
The 0100-77037 delivers exceptional signal accuracy, with a 16-bit resolution that captures even the smallest variations in input—critical for applications like pharmaceutical batch processing, where 0.1°C temperature shifts can affect product quality. Its advanced noise filtering technology ensures stable performance in high-electromagnetic-interference (EMI) environments, such as near large motors or transformers, where other modules might falter.
Hardware-wise, the 0100-77037 is built to endure. Its rugged stainless-steel housing resists corrosion from chemicals and moisture, making it suitable for washdown areas in food processing or outdoor installations in water treatment plants. The compact design allows for dense packing in control cabinets, saving valuable space without sacrificing airflow.
Compatibility is a standout feature: it supports industry standards like HART and FOUNDATION Fieldbus, enabling seamless communication with smart sensors and valves. This interoperability future-proofs systems, allowing easy upgrades to IIoT-enabled devices. Long-term reliability is assured by its wide operating temperature range and low power consumption, which reduces heat buildup and extends service life—critical for remote installations where maintenance access is limited.
Technical specifications:
Model 0100-77037
Brand AMAT
Type Analog Input Module (Multi-Signal)
Power Supply 24 V DC (1.2A max)
Operating Temperature -40°C to +70°C
Mounting DIN Rail (35mm)
Dimensions 65mm x 125mm x 80mm (WxHxD)
Weight 0.4 kg
Interfaces 8 analog inputs (supports thermocouples, RTDs, 4-20mA, 0-10V), HART, Ethernet/IP
Certifications CE, UL, ATEX, IECEx, FDA 21 CFR Part 11
Cooling Passive (no fans)
Environmental Rating IP20 (with optional IP65 enclosure)
Signal Resolution 16-bit
Update Rate 10 ms per channel
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
Application areas:
In the demanding world of industrial process control, where precision and durability are non-negotiable, the 0100-77037 has earned its place as a critical component. This module excels in oil and gas refineries, where it monitors and regulates flow meters and pressure sensors in high-pressure pipelines, ensuring safe and efficient crude processing. It’s equally vital in pharmaceutical manufacturing, where strict compliance with FDA standards requires consistent control over temperature and humidity in cleanrooms—tasks the 0100-77037 handles with unwavering accuracy.
Water and wastewater treatment plants rely on it to manage chemical dosing systems, precisely controlling the flow of coagulants and disinfectants to meet environmental regulations. In pulp and paper mills, where machinery operates under heavy vibration and moisture, the0100-77037 stands strong, synchronizing roller speeds and tension controls to prevent material waste. Used in industrial automation systems globally, it solves the challenge of bridging diverse field devices with central controllers, making it a go-to choice for engineers building robust, future-ready operations.
Related products:
0100-77038 – Same platform, with 16 analog inputs for high-density applications like large-scale chemical processing plants. 0100-77036 – Digital output companion module that pairs with 0100-77037 to control valves and actuators based on its input data. 0100-77039 – Explosion-proof variant certified for ATEX Zone 1, designed for hazardous areas in oil refineries and gas processing. 0100-77040 – Redundant power supply unit optimized for 0100-77037, ensuring uninterrupted operation during main power failures. 0100-77041 – Communication gateway that connects 0100-77037 to legacy Modbus RTU systems, simplifying retrofits. 0100-77042 – Calibration tool specifically for 0100-77037, enabling on-site verification of analog signal accuracy. 0100-77043 – DIN rail-mounted surge protector that shields 0100-77037 from voltage spikes in industrial power grids.
Installation and maintenance:
Before installing the 0100-77037, ensure the DIN rail is securely fastened to a metal cabinet—this provides proper grounding and reduces EMI interference. Leave at least 50mm of clearance above and below the module to maintain airflow, critical for preventing overheating in high-temperature environments like boiler rooms. For outdoor or washdown locations, use the optional IP65 enclosure and seal cable entries with heat-shrink sleeves to block moisture.
Maintenance should include bi-annual calibration checks using a certified signal generator to verify accuracy—this is especially important in pharmaceutical or food applications where compliance audits are strict. Inspect terminal blocks quarterly for tightness, as vibration in mills or refineries can loosen connections over time. Firmware updates, released annually, often include improved noise reduction algorithms; apply them during scheduled shutdowns to avoid disrupting processes.
