The 0100-71304 is a multi-protocol communication gateway designed to break down interoperability barriers between disparate industrial devices. As a core component of modular automation architectures, it converts signals and data formats between legacy systems (like RS-485) and modern protocols (such as Ethernet/IP or MQTT), enabling seamless communication across the entire plant floor.
Model 0100-71304
Brand AMAT
Type Multi-Protocol Communication Gateway
Power Supply 24VDC (18-30VDC) and 120VAC (90-264VAC) – redundant
Operating Temperature -40°C to 75°C
Mounting DIN Rail (35mm) or Wall-Mount
Dimensions 200mm (L) x 120mm (W) x 80mm (H)
Weight 1.2 kg
Supported Protocols Ethernet/IP, PROFINET, Modbus RTU/TCP, Profibus DP, DeviceNet, MQTT
Interfaces 2 x Ethernet (10/100Mbps), 4 x RS-485, 1 x USB-C
Certifications IEC 61010, UL 61010, ATEX Zone 2, DNV GL (marine)
Security Features AES-256 Encryption, Firewall, User Authentication
Environmental Rating IP66
The 0100-71304 is a multi-protocol communication gateway designed to break down interoperability barriers between disparate industrial devices. As a core component of modular automation architectures, it converts signals and data formats between legacy systems (like RS-485) and modern protocols (such as Ethernet/IP or MQTT), enabling seamless communication across the entire plant floor.
0100-71304
What distinguishes the 0100-71304 is its “plug-and-play” adaptability: it auto-detects connected devices and configures communication parameters, reducing setup time from days to hours. It fits into both new installations and retrofits, making it a favorite among integrators upgrading aging infrastructure without replacing every component. For engineers, its value lies in its ability to future-proof systems—supporting emerging protocols while keeping older, reliable equipment in service.
0100-71304
Main features and advantages:
The0100-71304 excels in protocol translation speed, with a latency of less than 5ms—critical for time-sensitive applications like real-time motion control. It supports over 20 industrial protocols natively, from Modbus RTU to Profibus DP, eliminating the need for multiple gateways in mixed-protocol environments. This versatility reduces cabinet clutter and simplifies system design.
Its hardware is built for endurance. Housed in a marine-grade aluminum enclosure, the 0100-71304 withstands operating temperatures from -40°C to 75°C and is rated IP66 for dust and water resistance—ideal for outdoor installations, such as solar farms or wastewater treatment plants. The module’s redundant power inputs (24VDC and 120VAC) ensure uninterrupted operation even if one supply fails, a lifesaver in mission-critical systems.
Security is another standout feature: the 0100-71304includes built-in firewall rules and data encryption (AES-256) to protect against unauthorized access, a must in smart factories where cyber threats are prevalent. It also offers edge computing capabilities, allowing basic data processing (like threshold alerts) to occur locally, reducing bandwidth strain on central servers.
Long-term reliability is ensured by its fanless design (no moving parts to fail) and industrial-grade capacitors rated for 100,000 hours of operation. This translates to minimal maintenance and a service life exceeding 10 years in typical industrial conditions.
Technical specifications:
Model 0100-71304
Brand AMAT
Type Multi-Protocol Communication Gateway
Power Supply 24VDC (18-30VDC) and 120VAC (90-264VAC) – redundant
Operating Temperature -40°C to 75°C
Mounting DIN Rail (35mm) or Wall-Mount
Dimensions 200mm (L) x 120mm (W) x 80mm (H)
Weight 1.2 kg
Supported Protocols Ethernet/IP, PROFINET, Modbus RTU/TCP, Profibus DP, DeviceNet, MQTT
Interfaces 2 x Ethernet (10/100Mbps), 4 x RS-485, 1 x USB-C
Certifications IEC 61010, UL 61010, ATEX Zone 2, DNV GL (marine)
Security Features AES-256 Encryption, Firewall, User Authentication
Environmental Rating IP66
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
Application areas:
In the complex web of industrial control systems, the 0100-71304emerges as a critical connectivity hub, solving the challenges of integrating diverse devices in high-demand environments. Consider a large-scale automotive assembly plant, where it acts as the nerve center linking robotic arms, conveyor belts, and quality inspection cameras. Here, it synchronizes data flow between legacy pneumatic controllers and modern IoT-enabled sensors, ensuring that assembly steps—from welding to painting—unfold with millimeter precision.
In pharmaceutical manufacturing, where compliance and traceability are paramount, the 0100-71304 shines. It connects temperature and pressure sensors in cleanrooms to centralized DCS systems, encrypting data to meet FDA 21 CFR Part 11 requirements. This seamless communication ensures that batch records are accurate and immutable, reducing the risk of costly audits or production halts.
Even in marine automation—think offshore drilling rigs or cargo ships—the 0100-71304proves its mettle. It bridges navigation systems, engine controls, and safety alarms, operating reliably despite salt spray, extreme vibrations, and fluctuating power supplies. Used in industrial automation, it’s the invisible translator that turns fragmented device languages into a unified system, making it indispensable for engineers tasked with building interconnected, future-ready factories.
Related products:
0100-71305 – Compact version of the 0100-71304 with fewer protocol options, ideal for small-scale machine integration.
0100-71310 – Industrial router that pairs with the 0100-71304 to extend communication to remote sites via 4G/5G.
0100-71302 – Protocol converter focused on legacy systems, supporting older formats like ASCII that the 0100-71304 doesn’t natively handle.
0100-71320 – Power redundancy module that ensures the 0100-71304 switches seamlessly between 24VDC and 120VAC inputs.
0100-71330 – Edge gateway with advanced computing power, working alongside the 0100-71304 for complex local data analytics.
0100-71308 – Fiber optic adapter that allows the 0100-71304 to communicate over long distances (up to 10km) without signal loss.
0100-71340 – Diagnostic tool that monitors the 0100-71304’s performance, alerting to protocol errors or latency spikes.
Installation and maintenance:
Before installing the 0100-71304, map out the network architecture to avoid protocol conflicts—for example, ensure Modbus RTU devices are on separate RS-485 buses if using both RTU and TCP simultaneously. Mount the gateway in a location with minimal electromagnetic interference (keep at least 1m from variable frequency drives) to maintain signal integrity. When wiring, use shielded Ethernet cables for industrial networks, and ground the shield at both ends to prevent noise.
For maintenance, perform quarterly firmware updates via USB-C or Ethernet—these often include new protocol support and security patches. Check redundant power inputs monthly with a multimeter to ensure both supplies are active; a failed input should trigger an alert, but visual confirmation is wise. Inspect cable connections annually, tightening terminal screws to prevent intermittent communication drops, especially in high-vibration environments like manufacturing floors.
