The 0100-71275 is a high-performance digital output module designed to convert control system commands into actionable mechanical or electrical responses in industrial environments. As part of a modular control architecture, it serves as the final link between PLCs or DCS systems and field devices like motors, valves, and solenoids.
Model 0100-71275
Brand AMAT
Type Digital Output Module (16-channel)
Power Supply 24 VDC (20-28 VDC operating range)
Operating Temperature -30°C to 70°C
Mounting DIN Rail (35mm standard)
Dimensions 175mm (L) x 90mm (W) x 60mm (H)
Weight 450 grams
Interfaces 16 digital output channels; PROFINET, DeviceNet
Output Rating 2A per channel (max), 10A total
Certifications UL 508, CE, IEC 61131-2
Protection Features Overcurrent, short-circuit, reverse polarity
Environmental Rating IP20 (with optional IP65 enclosure)
The 0100-71275 is a high-performance digital output module designed to convert control system commands into actionable mechanical or electrical responses in industrial environments. As part of a modular control architecture, it serves as the final link between PLCs or DCS systems and field devices like motors, valves, and solenoids.
0100-71275
What makes the 0100-71275unique is its ability to handle both high-current loads and rapid switching cycles without degradation. It fits seamlessly into existing automation ecosystems, compatible with major protocols like PROFINET and DeviceNet, making it a flexible choice for integrators upgrading legacy systems or building new ones. For engineers, its value lies in its dual focus on precision—ensuring commands execute exactly when needed—and durability, standing up to the harsh conditions of factory floors.
0100-71275
Main features and advantages:
The0100-71275 excels in fast, reliable switching, with a maximum response time of 2ms—critical for applications like high-speed sorting where split-second delays can cause misfires. Its output channels are individually fused, preventing a single short circuit from disabling the entire module; this built-in protection reduces downtime and simplifies troubleshooting.
Hardware-wise, the module is built to endure. Its housing is constructed from flame-retardant thermoplastic, rated to withstand temperatures from -30°C to 70°C, and resistant to oil, grease, and common industrial solvents. This ruggedness makes it suitable for both indoor control cabinets and outdoor installations, such as agricultural processing facilities where dust and moisture are prevalent.
Compatibility is another strength: the 0100-71275supports 16 independently configurable channels, each capable of switching 24VDC or 120VAC loads—eliminating the need for separate modules for different voltage requirements. It integrates smoothly with SCADA systems for remote monitoring, with built-in diagnostics that flag open circuits or overloads in real time.
Long-term reliability is ensured by its low power draw (less than 8W) and robust terminal blocks, which use spring-clamp connections to maintain tight wiring even under vibration. This design extends service life to an estimated 150,000 operating hours, translating to years of trouble-free performance in most industrial settings.
0100-71275
Technical specifications:
Model 0100-71275
Brand AMAT
Type Digital Output Module (16-channel)
Power Supply 24 VDC (20-28 VDC operating range)
Operating Temperature -30°C to 70°C
Mounting DIN Rail (35mm standard)
Dimensions 175mm (L) x 90mm (W) x 60mm (H)
Weight 450 grams
Interfaces 16 digital output channels; PROFINET, DeviceNet
Output Rating 2A per channel (max), 10A total
Certifications UL 508, CE, IEC 61131-2
Protection Features Overcurrent, short-circuit, reverse polarity
Environmental Rating IP20 (with optional IP65 enclosure)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
0100-71275
Application areas:
In the demanding landscape of industrial automation, the0100-71275 has established itself as a vital component in environments where precise digital control meets rugged operational demands. Consider semiconductor manufacturing facilities, where it orchestrates the movement of delicate wafers between processing stations. Its ability to deliver millisecond-accurate trigger signals ensures that etching and deposition equipment operate in perfect synchrony, directly impacting yield rates for high-value microchips.
In packaging lines for consumer goods—think beverage bottling or snack food packaging—the 0100-71275 acts as the nerve center for sorting and diverting systems. It processes input from optical sensors to identify defective products, then sends instant commands to pneumatic actuators to redirect flawed items, all while maintaining line speeds of up to 300 units per minute. This not only reduces waste but also keeps production targets on track.
Even in renewable energy setups, such as solar panel assembly plants, the0100-71275 proves its worth. It coordinates the alignment of robotic arms during panel lamination, ensuring that glass, cells, and backsheets bond uniformly—a critical factor in long-term panel efficiency. Used in industrial automation, it’s the reliability workhorse that bridges sensor data and mechanical action, making it indispensable for engineers tasked with optimizing throughput and precision.
Related products:
0100-71276 – 8-channel compact version of the 0100-71275, ideal for space-constrained panels in lab automation setups.
0100-71280 – Digital input module that pairs with the 0100-71275 to create a closed-loop control system, processing sensor data for immediate action.
0100-71278 – Isolated version of the 0100-71275, designed for high-noise environments like arc welding cells to prevent signal interference.
0100-71290 – Power distribution module optimized to supply stable 24VDC to the 0100-71275 and connected field devices.
0100-71305 – Relay output adapter that extends the 0100-71275’s capability to control high-voltage AC loads (up to 240V).
0100-71270 – Communication gateway that enables the 0100-71275 to interface with older RS-232-based control systems.
0100-71285 – Diagnostic module that provides real-time current monitoring for each 0100-71275 channel, alerting to potential overloads.
Installation and maintenance:
Before installing the0100-71275 , verify that the power supply can handle the total load of all connected devices—sum the current draw of each output channel and ensure it stays below the module’s 10A total rating. Mount the module on a grounded DIN rail, and use cable ties to secure wiring harnesses, preventing strain on terminal connections during thermal expansion. For outdoor use, pair it with the optional IP65 enclosure and apply dielectric grease to terminals to resist corrosion.
For maintenance, conduct monthly visual checks: inspect fuses (replace with identical ratings only) and check for loose wires, which can cause voltage drops. Test output response times annually using an oscilloscope to ensure they remain within the 2ms specification—degradation here can signal worn contacts. Firmware updates are available via Ethernet; schedule these during off-hours, and always back up configuration data first to avoid losing channel settings.
