The 0100-71141 is a rugged analog input module designed to bridge the gap between field sensors and industrial control systems. As part of a modular automation platform, it converts continuous physical signals—like pressure, temperature, or flow—into digital data that PLCs and DCS systems can process.
Model 0100-71141
Brand AMAT
Type Analog Input Module (8-channel)
Power Supply 24 VDC (18-30 VDC operating range)
Operating Temperature -40°C to 70°C
Mounting DIN Rail (35mm standard)
Dimensions 150mm (L) x 80mm (W) x 65mm (H)
Weight 320 grams
Interfaces 8 analog input channels; Modbus RTU (RS-485); Ethernet/IP
Certifications ATEX, IECEx, UL 508, CE
Cooling Passive (no fans)
Environmental Rating IP65 (when used with optional gasket)
Signal Types Supported 4-20mA, 0-10V, thermocouples (J/K/T)
The 0100-71141 is a rugged analog input module designed to bridge the gap between field sensors and industrial control systems. As part of a modular automation platform, it converts continuous physical signals—like pressure, temperature, or flow—into digital data that PLCs and DCS systems can process.
0100-71141
What sets the0100-71141 apart is its role as a translator: it takes messy, real-world signals (often noisy or weak) and cleans them up for accurate system decision-making. It integrates seamlessly with most major control architectures, from Allen-Bradley to Siemens systems, making it a favorite among integrators who value flexibility. For engineers, its value lies in its ability to reduce signal interference and extend sensor lifespans, ultimately lowering long-term maintenance costs.
0100-71141
Main features and advantages:
The 0100-71141 stands out for its exceptional signal conditioning capabilities. It filters out electromagnetic interference (EMI) and radio-frequency interference (RFI) common in industrial settings, ensuring that sensor data remains accurate even in crowded electrical environments. This translates to more reliable process control—critical in applications like pharmaceutical manufacturing, where even minor deviations can compromise product quality.
Its hardware design is built for toughness. Encased in a corrosion-resistant aluminum housing, the 0100-71141 handles operating temperatures from -40°C to 70°C, making it suitable for both indoor control cabinets and outdoor installations, such as oil refinery yards. The compact form factor (just 150mm in length) allows for dense mounting in tight spaces, a boon for retrofitting older systems with limited cabinet room.
Compatibility is another strength. The 0100-71141 supports a wide range of sensor types, including 4-20mA current loops, 0-10V voltage signals, and thermocouples (J, K, T types). It communicates via Modbus RTU and Ethernet/IP, enabling easy integration with SCADA systems for remote monitoring.
Long-term reliability is baked in, too. Its low power consumption (less than 5W) reduces heat buildup, while gold-plated terminals resist oxidation, ensuring stable connections over a 10+ year service life. This durability minimizes unplanned downtime—a key metric for plant managers tracking OEE (Overall Equipment Effectiveness).
0100-71141
Technical specifications:
Model 0100-71141
Brand AMAT
Type Analog Input Module (8-channel)
Power Supply 24 VDC (18-30 VDC operating range)
Operating Temperature -40°C to 70°C
Mounting DIN Rail (35mm standard)
Dimensions 150mm (L) x 80mm (W) x 65mm (H)
Weight 320 grams
Interfaces 8 analog input channels; Modbus RTU (RS-485); Ethernet/IP
Certifications ATEX, IECEx, UL 508, CE
Cooling Passive (no fans)
Environmental Rating IP65 (when used with optional gasket)
Signal Types Supported 4-20mA, 0-10V, thermocouples (J/K/T)
Contact Us Phone:+86 16626708626 WeChat/WhatsApp:+86 16626708626 Email: 3772179818@qq.com
Application areas:
In the high-stakes world of industrial process control, the 0100-71141 has become a cornerstone in environments where precision and durability are non-negotiable. Take chemical processing plants, for example—here, it regulates the flow of corrosive fluids through pipelines, ensuring exact dosing of raw materials in batch reactions. Its ability to withstand extreme pH levels and ambient chemical fumes makes it indispensable, preventing costly shutdowns caused by component failure.
In water and wastewater treatment facilities, the 0100-71141shines as a critical interface between sensors and control systems. It processes data from turbidity meters, pH probes, and flow sensors, translating real-time readings into actionable commands for pumps and valves. This ensures compliance with strict environmental regulations by maintaining consistent water quality metrics.
Even in heavy machinery manufacturing, where vibrations and temperature fluctuations are common, the 0100-71141 proves its mettle. It coordinates the timing of hydraulic presses and conveyor systems, reducing wear on mechanical parts by ensuring smooth, synchronized operation. Used in industrial automation, it’s the silent workhorse that keeps complex control systems running reliably, day in and day out.
Related products:
0100-71142 – 16-channel version of the 0100-71141, ideal for large-scale sensor networks in refineries.
0100-71151 – Digital output module that pairs with the 0100-71141 to execute control commands from processed data.
0100-71131 – Isolated analog input module, designed for high-noise environments like arc welding facilities.
0100-71201 – Power supply unit optimized to deliver stable 24VDC to the 0100-71141 and adjacent modules.
0100-71301 – Signal converter that adapts 0-5V sensors to work with the 0100-71141’s input range.
0100-71401 – HMI touch panel that displays real-time data from the 0100-71141 for on-site operators.
0100-71501 – Surge protection module to shield the 0100-71141 from voltage spikes in outdoor installations.
Installation and maintenance:
Pre-installation, ensure the mounting rail is grounded to minimize noise interference—this is critical for accurate signal reading, especially with low-level thermocouple inputs. Leave at least 25mm of clearance above and below the 0100-71141 to allow for airflow, even though it uses passive cooling. When wiring, use twisted-pair cables for sensor connections, and keep them separated from high-voltage power lines (minimum 300mm distance) to avoid cross-talk.
For maintenance, perform visual inspections quarterly: check for loose terminal screws (common after thermal cycling) and signs of corrosion, especially in humid environments. Calibrate the module annually using a precision signal generator to ensure accuracy—this is non-negotiable for FDA-regulated industries. Firmware updates can be done via Ethernet/IP; schedule these during planned shutdowns to avoid disrupting active processes.
